8M Octagonal Hot Dip Galvanized Steel Pole Metal Posts 135mm / 196mm Diameter
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
30FT 35FT Hot Dip Galvanized Steel Pole in 500kgs Design Load 69LV Power
-
HDG Galvanized Steel Pole 3.5m ~ 15m Height Options galvanized metal tubing
-
36.9m / s Ant i -wind Capacity galvanized metal pipe , steel transmission pole With Galvanization mi
-
Custmised Diameter 1 / 2 inch galvanized pipe octagon steel tubing GB11345 Grade Welding Standard
-
Low Voltage tapered steel pole , galvanized metal posts with Bituminous Painting
-
Burial Type ASTM A 123 Galvanized Steel Pole for Electrical Distribution Power Line
Product Details
Brand Name | BOSHENG | Place of Origin | China | |
Model Number | BS/GS - 06 |
Product Description
Certification:ISO9001:2008
8M Hot Dip Galvanized Octagonal Steel Pole , Metal Post for South Amercian Market
Material: |
Steel Q235, SS400 ; Q345 , Gr50. |
Yield strength of Material: |
Minimum yield strength ≥345n/mm2 |
Pole’s height: |
8M |
Section |
1 |
Wall thickness: |
3.0MM |
Pole's Shape : |
Octagonal |
Power: |
Low Voltage |
Welding |
Welding in accordance with standard of CWB and AWS D 1.1 |
Galvanization: |
Hot dip galvanization with min thickness 86µm on average in accordance with Chinese standardGB/T 13912-2002 or American standard ASTM A123, ISO: 2626-1985. |
Manufactury Capacity Per Day: | 300pcs |
Wall thickness Tolerance: |
+- 0.1mm from 2.3mm to 4mm. +- 0.2mm from 5mm to 20mm. +- 0.5mm from 22mm to 30mm |
Diameter: |
135mm / 196mm |
Finishing |
Hot Dip Galvanized |
Temperature range |
-35 °C~+45 °C |
Wind Speed: |
Aganist wind pressure of 120Km/h to 180Km/h. |
Install Type |
Burial Type |
Design Load: |
500 kgs |
Quality Control |
According to ISO9001-2008 requirements. |
Certificates |
ISO9001-2008, SGS Audited Supplier, The AAA grade certificate. |
Other | Less land occupation & easy maintenance |
Description:
Through the efforts of the company staff, the support and cooperation from all over the world. The company's products have been exported to Philippines, Malaysia, Australia, America, Africa, Latin America, Panama, Suriname, Costa Rica, Colombia, Jordan, Nigeria, etc. We have good export experience and with 1 container export to World in average every day.
Others Standard poles 25FT, 30FT, 35FT, 40FT,45FT
Height (ft) |
Thickness (mm) |
Butt Diameter (mm) |
Tip Diameter (mm) |
Design Load (kg) |
Yield Stress (MPA) |
Zinc Coating (microns) |
25 | 2.5 | 152 | 120 | 300 | 345 | 86 |
30 | 3.0 | 226 | 127 | 500 | 345 | 86 |
35 | 3.0 | 248 | 127 | 500 | 345 | 86 |
40 | 3.0 | 317 | 127 | 500 | 345 | 86 |
45 | 3.0 | 328 | 127 | 500 | 345 | 86 |
Production Process
Raw material test Cutting Bending Welding (longitudinal ) Dimension verify Flange welding Hole drilling Calibration Deburr Galvanization or powder coating or Bituminous painting Recalibration PackagesOur Services
1. Reply your inquiry in 24 working hours.
2. Experienced staffs answer all your questions in fluent English.
3. Customized design is available. UEM & UBM are welcomed.
4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.
5. Special discount and protection of sales are provided to our distributor.
6. Professional factory : We are manufacturer, specializing in producing all kinds of steel poles
for more than 10 years, competitive with good quantity.
7 Sample: We can send out sample for test in one week if the order quantity is big enough.
But the shipment charges is usually paid by your side, the charges will be rebounded when we have formal
order.
8. As an honest seller, we always use superior raw material, advanced machines,
skilled technicians to ensure our products to be finished in high quality and stable featu
