600 Watt Outdoor Cabinet Air Conditioner With Compressor / Outer Cover

Delivery Time:7-10 working days
Certification:ISO9001, CE, 3C, FCC, TLC

600 Watt Outdoor Cabinet Air Conditioner With Compressor / Outer Cover


Quick Details:

Place of Origin: Shenzhen, China (Mainland)	Rated Cooling Capacity : 600W
Brand Name: ESTEL	Rated Heating Capacity:300/500W (optional)
Model: TC06-60JFH/01(AC220V 60Hz)	Dimension: H×W×D 520×360×187mm
Product Name: Outdoor Cabinet Air Conditioner	Rated Input Voltage: AC220V/60Hz
Certification: ISO9001, CE, 3C, FCC, TLC	Rated Input Current: 1.2A
Cover Material: galvanized steel	Rated Input Power: 264W
Color: grey	Working Temperature: -20°C ~ +55°C
Protection Level: IP55	Noise: ≤62dB
Installation Mode: door mounted	Refrigerant: R134a
Support OEM	Cooling Method: compressor, active cooling

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union
Supply Ability:	14,000 sets per month
Delivery Time:	7-10 working days
Packaging Details:	carton + wooden case

1. Specifications

(1) Technical Parameters

Environmental Performance	working environmental temperature	-20°C ~ 55°C
	storage temperature	-40°C ~ 70°C
	working humidity	≤95%
Thermal Performance	rated cooling capacity	650W(L35 L35) 600W(L25 L35)
Electrical Performance	rated input current	1.4A(L35 L35) 1.2A(L25 L35)
	rated input power	308W(L35 L35) 264W(L25 L35)
	input voltage	AC208~230V/60Hz
Refrigerant	R134a
Noise	≤62dB

Dimension Diagram: H×W×D: 520×360×187mm

2. Description

TC06-60JFH/01 Air Conditioner is a full automation temperature control product. It uses intelligent controller to control the whole system of the air conditioner. According to the variation of environment temperature, the intelligent controller can automatically detect, operate and record the whole system’s operating time, power consumption, event and historical data. It can store 100 event records and 1280 historical data records, and can enquire 256 days’ daily record information.

3. Application

The product is widely applied in telecom cabinet, small and medium sized telecom room, UPS room, outdoor base station room, etc.

  4. Features Strong adaptability High intelligence High precision High reliability Low noise Low energy consumption With 4 way switching value detection With 1 way room air conditioner control Voltage input range: 220VAC±15% 60Hz With dry contact alarm output   5. System Principle Diagram   6. Electrical Wiring Diagram

Wiring Ports:

L N PE : power supply port (voltage input: 220VAC±15% 60Hz)

F+ F- : direct ventilation output port

AL1 AL2: general alarm output port

A+ B- SGND: RS485 communication port

N: not connected pin

7. System Control 7.1 Function and Application

ET731 intelligent air conditioner controller is a universal intelligent controller, controlling with highly integrated STC SCM. It can intelligently control thermostatic cabinet air conditioner working and hydrogen exhausting, including functions such as fault self diagnosis, power-on self start, or restart after unexpected failure caused by other reasons. The controller is compatible with all types of air conditioners in the market.

The controller, with the features of advanced performance, easy installation and setting, are widely used in telecom cabinet, small and medium sized telecom room, UPS room, outdoor base station room, etc.

  7.2 Technical Parameter 2×16 Chinese/English shift LCD display, user friendly; Simultaneously display temperature and humidity inside the box and communication room temperature; Temperature measurement accuracy: 0.1 °C; humidity measurement accuracy:5%; Can store 180 days’ daily event record, 1
