Soundboss P10 Full Color Rental Led Screen Video Wall for Advertising With CE & RoHS

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	S&B		Place of Origin	China
Model Number	SBO-P10

Delivery Time:10~20 days
Certification:CE,RoHS，CCC

Soundboss P10 full color rental led screen video wall for advertising with CE & RoHS

2011 Asian cup LED supplier

1. CE & RoHS certificate

2. 24 months warranty, life long free tech-support

3. Wide visual angle, smooth surface

4. Excellent contrast ratio, high resolution

5. Perfect uniformity, no mosaic

6. Light weight, easy to installation

7. Built-in gear for gap adjustment.

Option item: SBO-P10, P12, P16, P20, P25, P31.25 (Outdoor models)

SBI-P4, P5, P6, P7.62, P8, P10, P12 (Indoor models)

Application:

Commercial advertising, Stadium perimeter, mobile media, night club, entertainment events, business establishments;

Advantage:

1. High Contrast ratio: 4000:1

2. First-class LED chip

3. Clear vivid image quality

4. Long life time of more than 70, 000 hrs.

5. Easy Installation & Operation

SBO-P10 (Pitch 10mm outdoor full color-1/4 scan)
Colour temperature	5000~9000 k
Pixel structure	φ3 oval lamp, 1R1G1B
Pixel pitch	10mm
Pixel density	10, 000 dots/㎡
Luminance	7, 500cd/㎡
Module dimension	160mm(W) * 160mm(H)
Module resolution	16 pixel(W) * 16 pixel mm(H)
Cabinet dimension	1280 * 960mm
Cabinet resolution	128 * 96
Cabinet area	1.229 sq. meter
Optimal visual distance	>10m
Visual angel	110 / 50 degree (H/V)
Max power consumption	≤1200w / ㎡
Average power consumption	≤750w / ㎡
Brightness adjustment	Adjust according to the environment
brightness software (0%-100%adjustable)
Gray scale	point by point 4096 gray grade levels of
each color, 16 bits γ correction available
Drive mode	1/4 dynamic scan, constant current
Frame frequency	≥60HZ
Refresh frequency	≥480HZ
Input voltage	AC 90~260 volts
Operation temperature	﹣40℃~ +65℃
Operation humidity	10％～90％
Input signal	S-video, RF, RGB, Yuv, YC, composite…
Control system	DVI card + master control card + receiver card
MTBF	>5000 hrs
Life span (50% brightness)	100, 000 hrs
Malfunction dot rate	1/10000
Ingress protection rate (Front/ rear)	IP65 / IP54
Cabinet material	Epoxy paint coated, aluminum / iron
Application:	Rental / Permanent inst
