High-end Drip Corretto Coffee Bag Packing Machine by Three Sides Seal With Outer Envelop

//Brief Introduction://

1) Automatic one-off finished packaging machine;

2) Coffee powder/Ground coffee;

3) New heat sealing;

4) Inner drip bag; Filter paper; with outer envelop;

5) High Quality.

6) All-round process: filing, weighting, bag forming, sealing, cutting and counting etc.

7)International Approval : ISO9001:2008

8)Quality Approval : Certification of Compliance

9)Experience : 12 Years Manufacturing

//Application: //

It is suitable for 5 to 15gram drip coffee inner and outer bag packaging.

//Features: //

1.Outer bag sealing is controlled by the stepper motor, ensuring accurate and stable bag length positioning.

2.Adopts PID temperature controller for more accurate temperature adjustment.

3.Adopts PLC control system and touch screen color monitor device, machine is very easy to operate.

4. The main machine parts is made of SUS304 stainless steel, so it ensures hygiene products output.

5. Some cylinders are imported, ensuring the accuracy and stability of the machines’ performance.

6. It can make the inner and outer bag at the same time automatically, which would highly improve the working efficiency.

7. Adopts automatic conveyor system.

8. Options: Date code printer.

//Technical Data://

Bag type:  new heat sealing

Packing material:   Paper/Plastic, Plastic/Aluminum/Plastic, Paper/Aluminum/Plastic, Filter paper

Feeding system:   Volumetric cup filler

Package range:    5-15g

Inner bag size:    L:50-75mm , W:50-90mm

Outer bag size:    L:85-120mm , W:75-100mm

Inner bag film width (180mm):   Bag size: L90mm*W75mm

Outer bag film width(200mm):    Bag size: L120mm*W100mm

Power supply:   Single phase, 220V, 50HZ, 3.7KW

Packing speed:   30-60bags/min

Machine weight:   400KGS

Machine dimension:   1200*900*1900mm (L*W*H)
