Self Aligning Auto Welding PU Pipe Rollers Siemens Electric Controls 110V-600V
Negotiable
/ Piece
1 Piece(Min.Order)
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Pressure Vessel Welding Automation Equipment Pipe Rollers Self Aligning
-
5T - 500T PU Rollers Self Aligning Welding Turning Rolls 4KW Wired / Wireless Control
-
Self Adjustable Inverter Control Welding Rotators With Motorized Bogie
-
High Frequency Welding Turning Rolls CE Certified for Tower Fabrication Line
-
Automatic T / H Beam Production Line , Submerged Arc Welding Machine High efficiency
-
4000mm H Beam Gantry Automatic Welding Assembling Machine With Saw Welder
Product Details
| Brand Name | Sencan | Place of Origin | China | |
| Model Number | HGZ |
Product Description
Certification:CE
Coated PU Wheel Pipe Welding Rotator 110V - 600V With 50ton Capacity
Kindly Noted:
1. Model from 5T-100T, others please let us know.
2. One set of welding turning rolls include one drive & one idler, also customer can choose other
combinations.
3. Voltage standard is 380V , 50HZ , 3PH. Other voltage please kindly let us know.
4. Control panel is wired control ,or you can choose wireless control.
5. If need more special requirements ,we’ll study with our engineer.
6.The revolve adopt A.C. Inverter motor driving.
Applications:
1. pressure vessel
2. pipe manufacturing industries
3. wind power fabrication
4. any heavy cylindrical job
5. chemical and fuel storage tank fabrication
Specifications:
| Type | Max loading (kg) | Vessel diameter(mm) | Dia. and width of the wheel(mm) |
Roller linear velocity(m/h) 6-60 |
Power of motor(kw) |
|
| Rubber rollers | Metal rollers | |||||
| HGZ-5 | 5000 | Φ250-2300 | Φ250×100 | 2×Φ240×20 | 0.75 | |
| HGZ-10 | 10000 | Φ320-2800 | Φ300×120 | 2×Φ290×25 | 1.5 | |
| HGZ-20 | 20000 | Φ500-3500 | Φ350×120 | 2×Φ340×30 | 2.2 | |
| HGZ-40 | 40000 | Φ600-4200 | Φ400×120 | 2×Φ390×40 | 3 | |
| HGZ-60 | 60000 | Φ750-4800 | Φ450×120 | 2×Φ440×50 | 4 | |
| HGZ-80 | 80000 | Φ850-5000 | Φ500×120 | 2×Φ490×60 | 4 | |
| HGZ-100 | 100000 | Φ1000-5500 | Φ500×120 | 2×Φ490×80 | 5.5 | |
| HGZ-150 | 150000 | Φ1000-6000 | / | Φ620×220 | 6 | |
| HGZ-250 | 250000 | Φ1800-7500 | / | Φ660×260 | 11 | |
| HGZ-500 | 500000 | Φ1800-8000 | / | Φ750×400 | 15 | |
Description:
Welding rotator is used to weld,polish and assemble the cylinder-shells,and to line the shells with rubber.It can be aligned by itself according to the size of the shell, it can be controlled with AC frequency converter,and the linear velocity is displayed by the digital.The distance between the wheels ,could adjust by bolt or manual lead screw.To realize the diameter could suit for the workpiece.
We also can design the customize various types of the welding rotator in accordance with the customers requirement.
Brand using:
﹡ Inverter is made in USA Danfoss / Taiwan Delta /Japan Yaskawa
﹡ Motor Brand is UK Invertek /Taiwan Qinwei / Siemens
﹡ Electrical components is made by Schneider /Siemens/Fuji
﹡ Reducer is made by Kaibo/Guomao
﹡ Wireless Control box is made by Taiwan by Yuding
﹡ Bearing is made by NTN / Harbin
