Complete Automatic Aluminum Foil Container Making Machine Line
Model: SEAC-45A
Units: Automatic Feeder+Automatic 45Ton Press+Cavities Mould+Auto Stacker+Scrap Sucker & Auto Presser.
It fit for all common size Aluminum Foil Container production requested. The Big capacity could to cover big range of size products. Lower power requested than other old model machines.
Specification:
1.Raw material: Aluminum foil; Thickness: 0.040mm ~0.250mm;
Alloy: 8011,8006,3003,3005; Temper O to H26;
2.Good Japan's Inverter, PLC and 10inch Touch Screen control system;
3.Max. width of Aluminum foil: 600mm;
4.Max. diameter of Aluminum foil: 700mm;
5.Core diameter of Aluminum foil: 76mm(152mm as Optional );
6.Working speed: 40-75 times/min;
7.Total Power: 7.5kw+2kw+2kw+1kw;
8.Compressed air needed: 0.5- 0.8 Mpa, 0.2m3/min;
9.Install dimension: 5800*2600*3200mm;
Technical Data:
ntainer size: single cavity 450*330*72mm ;
Slide block stroke: 120-200mm (Standard:180mm);
Automatic mould adjust unit: 0.5kw;
Work plate dimension: 700*950mm;
Mould handle hole dimension: 50*60mm(Diameter*Depth);
Power: 4P, 380/220V, 50/60Hz;
Net weight: 6000kg.
SEAC-45A is the best model for Aluminum foil container production now, it have instead of the old 40Ton model, as it is more big capacity to cover container size !
Complete automatic level upgrade your factory capacity, lead your company be higher level competition and situation.
