Home > Products > Guardrail Roll Forming Machine > 15 Forming Station Crash Barrier Roll Forming Machine for Highway Guardrail TW-W312
15 Forming Station Crash Barrier Roll Forming Machine for Highway Guardrail TW-W312
Negotiable
/ Set
1 Set(Min.Order)
- 20 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Forming Speed 10 - 12m/min W Beam Guardrail Forming Machine for Crash Barrier TW-W312
-
15KW Highway Guardrail Roll Forming Machine With 7 Rollers Leveling For W Beam Guardrail
-
Forming Speed 10 - 12m/min W Beam Guardrail Forming Machine for Crash Barrier TW-W312
-
W Beam Guardrail Roll Forming Machine For W Beam, W Beam Guardrail
-
380V, 3 Phase 50Hz Two Wave Guardrail Roll Forming Machine for Highway Guardrail
-
30KW, 3 Phase 50Hz 2 Wave Beam Roll Forming Machine With 10 - 12m/min Working Speed
Product Details
| Place of Origin | China | |
| Model Number | TW-W312 |
Product Description
15 Forming Station Crash Barrier Roll Forming Machine for Highway Guardrail TW-W312
Summary of Crash Barrier Forming Machine
This crash barrier roll forming machine mainly consists of decoiler, guide device, levelling system, hydraulic station, punching, roll forming system, cutting system and runout table.
Thi
Material Thickness: 2-4mm
Forming Station: 15 excluding the feeding rollers and leveling rollers
7 Rollers leveling
Principal Axis Diameter: ￠100mm
Working Speed: 10-12m/min
Main Power: 30KW
Leveling Power: 2.2KW
Hydraulic Power: 15KW
Dimension of Machine: 11500MM X 2000 MMX1600MM ( LXWXH )
Gross Weight of Machine: about 18 Ton
Voltage: 380V, 3 Phase 50Hz
Our Advantaegs
High Quality
Reasonable Price
Good after Service
1 Year Warranty
More Than 10 Years Experience
