Low Insertion Loss 1550nm Laser Diode , DFB Pigtailed Laser Diode
- T/T L/C D/P D/A
- 7 days
You May Like
-
Low Dark Current FB Pigtailed Components 1550nm Laser Diode 6mw High Power
-
Integrated High Isolation 1310nm Laser Diode , FP Pigtail Cheap Laser Diode
-
1.25G - 2.5G Bandwidth FP Laser Diode 1310 Nm For Light Source
-
1550nm Laser Diode With CWDM Butterfly Package for Long Haul CWDM Transmission
-
CWDM 1550nm Cheap Laser Diode With 2.5G~4.3G Package For CATV
-
Digital Optical Transmission 1550nm Laser Diode With FP Pigtail Package
Product Details
| Place of Origin | China | |
| Model Number | 1550nm laser diode |
Product Description
Certification:RoSH, ISO9001
1550nm DFB Pigtailed Components
Features
1. High stability of DFB lasers die
2. Low threshold current , low operating current
3. Integrated high isolation , low insertion loss
5. Built - in optical isolator
6. Low capacitance and low dark current
Applications
CATV Reverse Transmission
Other Analog or Digital Optical Transmission
Absolute Maximum Ratings
|
Parameter |
Symbol |
Min. |
Max. |
Unit |
Test Condition |
|
Storage Temperature |
Tstg |
-40 |
100 |
℃ |
- |
|
Operating Temperature |
Top |
-40 |
85 |
℃ |
- |
|
Forward Current(LD) |
If(LD) |
150 |
mA |
||
|
Reverse Voltage(LD) |
Vr(PD) |
2 |
V |
CW |
|
|
Forward Current(PD) |
If(LD) |
2 |
mA |
||
|
Reverse Voltage(PD) |
Vr(PD) |
15 |
V |
CW |
|
|
Soldering Temp |
- |
- |
260 |
℃ |
- |
|
Soldering Time |
- |
- |
10 |
S |
S |
Optical & Electrical Characteristics
|
Parameter |
Symbol |
Min. |
Typ. |
Max. |
Unit |
Test Condition |
|
Rated Power |
Po |
1 |
- |
4 |
mW |
Ith+20mA |
|
Slope Efficiency |
SE |
0.2 |
mW/mA |
|||
|
Threshold Current |
Ith |
10 |
15 |
mA |
- |
|
|
Forward Voltage Drop |
Vop |
- |
1.0 |
1.2 |
V |
CW, Ith+20mA |
|
Cent Wavelength |
λc |
1540 |
1550 |
1560 |
nm |
- |
|
Spectrum Width(-3dB) |
Δλ |
- |
0.5 |
1 |
nm |
Ith+20mA |
|
Side-mode Suppression Ratio |
SMSR |
35 |
- |
dB |
- |
|
|
Bandwidth |
Bw |
2.5 |
GHz |
|||
|
Monitor Current |
Im |
100 |
900 |
uA |
CW, Ith+20mA |
|
|
Dark Current of Monitor |
Id |
- |
- |
100 |
nA |
5V |
|
Optical Isola |
