Wide Bandwidth FP TOSA Laser Diode 1550nm For Sensor And Light Source
- T/T L/C D/P D/A
- 7 days
You May Like
-
RoSH Approved 650nm 5mw Laser Red TOSA Receptacle With Universal Adapter
-
Wavelength 1310nm High Power Pulse Laser DFB 2.5Gb/s For OTDR System
-
Wide Bandwidth 1310 / 1550nm FP TOSA Laser Diode Low Capacitance
-
Large Area Ingaas Pin Photodiode Module For Power Meter 300-2000um
-
Telecommunication Application InGaAs 1.25G PIN TIA With LC Package
-
High Stability OTDR Coaxial Pigtail 4pin 1310nm Laser Diode Approved ISO9001
Product Details
| Place of Origin | China | |
| Model Number | FP TOSA |
Product Description
Certification:ROSH, ISO9001
1550nm FP TOSA Components
Features
1. High stability of FP lasers die
2. Low threshold current , low operating current
3. Low capacitance and low dark current
Applications
Light source
Absolute maximum ratings
|
Parameter |
Symbol |
Min. |
Max. |
Unit |
Test Condition |
|
Storage Temperature |
Tstg |
-40 |
100 |
℃ |
- |
|
Operating Temperature |
Top |
-40 |
85 |
℃ |
- |
|
Reverse Voltage |
Vr |
- |
2 |
V |
CW |
|
Soldering Temp |
- |
- |
260 |
℃ |
- |
|
Soldering Time |
- |
- |
10 |
S |
S |
Optical & Electrical Characteristics
|
Parameter |
Symbol |
Min. |
Typ. |
Max. |
Unit |
Test Condition |
|
Rated Power |
Po |
0.2 |
- |
2 |
mW |
Ith+20mA |
|
Threshold Current |
Ith |
3 |
- |
12 |
mA |
CW |
|
Forward Voltage Drop |
Vop |
- |
1.1 |
1.5 |
V |
CW, Ith+20mA |
|
Cent Wavelength |
λc |
nm |
- |
|||
|
1540 |
1550 |
1560 |
||||
|
Spectrum Width(-3dB) |
Δλ |
- |
0.3 |
0.5 |
nm |
Ith+20mA |
|
Bandwidth |
Bw |
1.25 |
2.5 |
- |
GHz |
RI=50Ω |
|
Monitor Current |
Im |
100 |
900 |
uA |
CW, Ith+20mA |
|
|
Dark Current of Monitor |
Id |
- |
- |
100 |
nA |
CW, Ith+20mA |
|
Optical Isolation |
ISO |
30 |
- |
- |
dB |
25℃ |
PIN Definition
Drawing
Order Information
TLD-FXXX-XXX
|
T |
LD |
-F |
X |
X |
X |
-X |
X |
X |
|
Mode |
Product Type |
Chip |
Wavelength |
Insolator |
Bandwidth |
Connector |
Pin |
Power Range |
|
F:F |
