Two Roll Mill Shredder Tyre Recycling Equipment High Output Portable

Two Roll Mill Shredder Tyre Recycling Equipment High Output Portable

Specifications

Features of two rolles mill :

1. Two roll mill is used to get the rubber powder in different sizes.

2. Our two roll mill is good for Energy saving, environmental protection and potential market.

3. All two roll mill have 2 years warranty and life long time technical support.

4. Warmly welcome you come and vist our factory to check and study our two roll mill.

The advantages of two roll mill:

1. Crusher roller speed ratio: Ours is 1: 2.5, while the old type roller speed ratio is 1: 1.38.

2. Roller structure: Our two rollers are both grooved, which increase the friction and then

improve the output, while the old type is one with groove, and the other is smooth.

3. Roller material: The roller is made by Welding wear resistant alloy materials, 5Cr6MnMo.

We can offer you 3 years warranty of the roller. While the old types machine use cast iron to

make the rollers, very easy to break or crack in two .

4. Machine feature: Our machine is energy saving 1/3. For example, producing 1T powder,

our machine electricity consumption is only 150°, while their electricity consumption is about

250- 280° in making 1T powder.

5. Bearing: Our machine use rolling bearing, there are 8 pieces bearing inside, while the old

machine use the slide bearings ( bush) , which is not as good as ours.

1. First, we need to cut and draw out the bead wire of the tire by the Compound Tire Cutter

and Extractor,

2. Then we can put the tire into the Tire Crusher by the conveyor, the tire will be crushed

into small pieces with the size of 50x50mm.

3. And those small pieces will be conveyed to the Secondary Crusher to be crushed into

small particles of 6-12mm.

4. Now we need a Magnetic Separator to separate the steel fiber from the rubber particles,

and a Square Magnetic Vibrator to separate the coarse fiber from the rubber particles by

vibrating.

5. The coarse fiber will be collected in a box and the rubber particles will be delivered to a

third Rubber Shredder to be shredded smaller of 1-4mm.

6. And then we need a Static Vibrator to gather the small fiber into clumps by static force,

and to filter the rubber particles by screen.

7. The fiber clumps will be stored in the Fiber Collecting Machine by conveyor, while the

rubber particles will be sent to the Airflow Classifier,

8. The residual fiber will be blowed to the Fiber Collecting Machine by the Airflow Classifier,

and the purified rubber particles will be collected by the Storage Bin,

9. And then be delivered to the Rubber Grinder, so the rubber particles will be grinded

into rubber powder.

10. Then the rubber powder will be separated by the Three-layer Vibrator according to its

size, and be packed automatically by the Packing Machine.

11. The exhaust gas and dust will be collected by the Cyclone Collector, then the dust will

be absorbed by the Dust Separation Machine,

12. while the gas will be filtered by Activated Carbon in the Air Purifier and be emitted to Air.

FAQ:

A. On the one hand, Machine quality is the life of enterprise.all our business due to supplying

high quality products and honest management.
On the other hand, the good quality products are the live advertisement in your country, it can

attract more good customers for us. We will absolutely seize this great opportunity to satisfy

you and satisfy your market with perfect products.

Q2. Can you guarantee the capacity as you mentioned ?

A. Defin
