Help Center26 / 35KV Medium Voltage Underground PVC Insulated Cable Single Core
Related Products
-
0.6 / 1kv Low Voltage PVC-Insulated Cable Aluminum Conductor 5 * 16mm2NegotiableMOQ: 1 Piece -
Multi Core 1.8 / 3KV Low Votage PVC Insulated Cable / Armoured CablingNegotiableMOQ: 1 Kilogram
-
1kv Fire-resistant PVC Insulated Cable / Steel Wire Armoured CableNegotiableMOQ: 1 Piece
-
3 Core PVC Insulated Electrical Armoured Cable And Wires Copper ConductorNegotiableMOQ: 1 Kilogram
-
Low Voltage PVC Insulated Cable Low Smoke Zero Halogen Power CableNegotiableMOQ: 1 Piece
Cable Wire
1.Responsible within 12 hours
2.Directly Factory Sales
3.CCC,ISO9001,OHSAS,TLC Honor
Description:Cable Wire
Specification: YJV 26/35KV 1*300
Application:
It is used to transmit and distribute power in power transmission and distribution system of 35kV or lower.
It is generally applied to the fields including power, construction, mines, metallurgy, petrochemical industry and communication in complete replace of oil immersed paper insulated power cable and in partial replace of PVC insulated power cable.
Using Features:
1. Rated voltage: Uo/U: 26/35kV, 21/35kV, 12/20 kV (24 kV), 8.7/10kV, 8.7/15kV, 6/6kV, 6/10kV.
2. No. of core: Single-core, Three-core.
3. The highest allowed operating temperature of conductor for long-term working is 90oC. In short-circuit (Max. Long-term is no more than 5 seconds). The highest temperature for conductor is no more than 250.
4. D.C Resistance of the conductor complies with the stipulations of GB/T3956-1997.
5. The environment temperature should be no lower than 0 when lay. Otherwise it should be preheated.
6. The cable is laid without horizontal drop limit. The Min. Bending radius of three-core cable should be no smaller than 12 times of cable outer diameter.
7. Working Frequency Voltage Test:.
For cable with Uo of 3.6kV or lower: 2.5Uo+2kV/5min without puncture.
For cable with Uo of 3.6kv~18kV: 3.5Uo/5min without puncture.
For cable with Uo of 21kV and 26 kV: 2.5Uo/30min without puncture.
8. Partial Discharge Test: The discharge volume should be no more than 10pC under 1.73Uo for the cable.
This series includes:
Copper (aluminum) core, XLPE insulated and sheathed power cables.
Copper (aluminum) core, XLPE insulated, PE sheathed power cables.
Copper (aluminum) core, XLPE insulated, steel tape armoring PVC sheathed power cables.
Copper (aluminum) core, XLPE insulated, steel tape armoring, PE sheathed power cables.
Copper (aluminum) core, XLPE insulated, steel wire armoring, PVC sheathed power Cables.
Copper (aluminum) core, XLPE insulated, steel wire armoring, PE sheathed power cables
Rated voltage: 0.6/1kV, 3.6/6kV.
Number of cores: 1 to 6.
Relative manufacturing standards: IEC60505, BS, DIN.
Packing: Wooden drum, steel wooden drum.
Power Cable
-Conductor:
Solid or stranded copper
--Insulation:
Cross-linked polyethylene( XLPE or PVC)
--Circuit Identication:
The insulation shall be red, black
---Filler:
Polypropylene lament with lapped binding tape
--Inner Sheath:
Polyvinyl chloride (Black)
--Armor:
Galvanized steel wire
--Core-covering:
Binding tape
-Outer Sheath:
Polyvinyl chloride (Black)
-Application:
For use in ducts, trays and direct burial in ground. The cable is subject to immerse in water all the time.
-Standards / Testing Specications:
IEC 60502-1.
The type, Name, Suitable areas:
|
Type |
Name |
Suitable areas |
|
|
Copper-conductor |
AL-conductor |
||
|
YJV |
YJLV |
XLPE-insulated cable sheathed with PVC |
Indoor, tunnel, cable channel |
|
YJY |
YJLY |
XLPE-insulated cable sheathed with polythene |
|
|
YJV22 |
YJLV22 |
XLPE-insulated cable sheathed with PVC and armored with steel tape |
