Custom Copper Conductor PVC Insulated Cable Electrical With CCC
Specifications
PVC-Insulated Cables
1.High Degree Copper Conductor
2.Durable outer Sheath
3.Quick Delivery & Reliable Quality
4.CCC Honor
1. The cable was suitable for AC rated voltage not exceeding 3.6/6KV.
2. All the characteristics & Technology are referenced by
A: National Standard GB/T12706-2008
B: International Standard IEC60502-1:2004,60502-2:2005
3.The Sheathing Insulated Power Cables with the Rated Voltage 1kv to 35kv and Its Attachment
The sue characteristic & index of electrical characteristics:
A.Suitable installation temperature:≥0°C B.Regular working temperature of conductor:≤70°C C.Under the condition of short circuit(the max. continuing time should not exceeding 5 seconds) the max. operation temperature:160°C D.the permissible minimum bending radius: single core:20D multicore: 20DE: The Following Tested cables of the Ac Votage
|
KV Rated voltage |
0.6/1 | 1.8/3 | 3.6/6 |
|
KV Test voltage |
3.5 | 6.5 | 12.5 |
|
min Continuing time(min.) |
5 | 5 | 5 |
F: The DCR of conductor comply with the rules of GB/T3956-2008 The Conductor of Cables
|
Type |
Name | Suitable Range | |
|
Copper-Conductor |
Aluminum-Conductor |
||
|
VV |
VLV |
PVC insulated and sheathed power cable |
Installation in such place as indoor, tunnel, pipeline, cable channel, and flammable and deep-corrosion areas; the mechanical force is unavailable |
| VY | VLY |
PVC insulated and sheathed power cable |
Installation in such place as indoor, tunnel, pipeline, cable channel, and flammable and deep-corrosion areas; the mechanical force is unavailable |
| VV22 | VLV22 |
insulated and sheathed cable with copper tape |
Installation in such place as indoor, cable channel, underground and deep-corrosion areas; the lager tension is unavailable. |
| VV23 | VLV23 |
PVC insulated and sheathed cable with steel tape |
Installation in such place as indoor, cable channel, underground and deep-corrosion areas; the lager tension is unavailable. |
| VV32 | VLV32 |
PVC insulated and sheathed cable armored with thin steel wire |
Installation in such place as underground, vertical shaft, water and deep-corrosion areas; the lager tension is unavailable. |
| VV33 | VLV33 |
PVC--insulted and polythene—sheathed cables armored with thin steel wire |
Installation in such place as underground, vertical shaft, water and deep-corrosion areas; the lager tension is unavailable |
| VV42 | VLV42 |
PVC insulated and sheathed cable armored with thick steel wire |
Installation in such place as underground,vertical shaft, water and deep-corrosion areas; the lager tension is unavailable. |
| VV43 | VLV43 |
