Water Lubrication Oil Free Screw Compressor 12.5 Bar Working Pressure

Water Lubrication Oil Free Screw Compressor 12.5 Bar Working Pressure

Quick Detail:

1. Model: KS(v)37F(W)-8   KS(v)37F(W)-10    KS(v)37F(W)-12.5

2. Type of cooling:Air cooling

3. Air delivery (M3/min):1.6~6.6 1.3~5.8 1.0~4.8

4. Workingpressure(bar) :8  10  12.5

5. Motor power:37 KW

6. Voltage:AC 380V/50HZ

7. Starting method:Y-Δ starting

8. Noise:66±5dB(A),

9. Outlet air temperature:Ambient temperature + 15 °C

10. Pipe connection diameter:Rp11/2

11. Weight:920

12. DIMENSION(L×W×H):1000×1600×1470

Specifications

11KW Oil Free Screw Type Compressor
1. Germany air end
2. Double screw
3. Oil free screw air compressor
4. Energy saving

Features:

1. Safe and oil free air quality
2. Original air import air end
3. Meeting environmental protection requirement
4. Low noise design
5. Low cost of maintenance
6. Long service life

Applications:

Oil free screw air compressor are widely used in industries that require high quality air sources such as: Pharmaceutical, food, electronics, chemical, packaging, etc. 100% pure compressed air is a necessary procedure to guarantee satisfactory crafts and product quality, which ensures the production of high-end products safely and risk-free.

The lubrication system of an oil free screw air compressor is an individual fuel recycling unit. The compression chamber and the bearings were separated by a set of sealed high-performance mechanical assembly. The lubricating oil can only flow in the enclosed area and is prevented to enter the compression chamber, which only contains 100% pure compressed oil-free air. The users could obtain 100% pure compressed air with some slight post-treatment of water and dust removal.

 Specification
