Home > Products > Microwave Components > DC- 50GHz Coaxial Transfer Switch Microwave Components AV80104
DC- 50GHz Coaxial Transfer Switch Microwave Components AV80104
- T/T L/C D/P D/A
- 7 days
You May Like
-
2.4mm Directional Coaxial Directional Coupler / Microwave Component
-
Microwave Components 50 Male Calibration Kit Fixed Load for Measure Laboratory
-
AV31101 Calibration Kit Microwave Components Type N50 Coaxial Port
-
40 dB Programmable Step Attenuator Broad Bandwidth Frequency Up To 50GHz.
-
Fix Attenuators Connectors Microwave Components Broad Bandwidth
-
10W 40GHz 30 dB Attenuator Microwave Components High Reliability
Product Details
| Brand Name | NFCase | Place of Origin | China | |
| Model Number | AIA-1 |
Product Description
Certification:CE,FCC,MSDS
AV80104 DC～50GHz Coaxial Transfer Switch
General Description:
The AV80104 transfer switch can be used in many different applications to increase system flexibility and simplify system design. The AV80104 series of DPDT switches provide the performance you need from DC to 50GHz.
Functional Diagram:
Specifications: (Conditions: Ta= 25℃)
|
Parameter |
AV80104 |
|
Frequency range |
DC-50 GHz |
|
SWR(Max) |
1.1(DC-4GHz) |
|
Insertion loss dB(Max) |
0.4(DC-4GHz) |
|
Isolation dB(Min) |
90(DC-4GHz) |
|
Maximum power input(W Max) |
1 |
|
Switching speed (ms Max) |
20 |
|
RF repeatability (dB Max) |
0.05 |
|
Operating life (Min) |
1 million |
|
Connector type |
2.4mm(f) |
|
Supply voltage range(V) |
22-28(rating:+24V) |
|
Relay structure |
Latching |
Typical Performance:(Conditions: Ta= 25℃)
Absolute Maximum Ratings:
|
Min. |
Max. |
|
|
RF Input Power |
- |
2 W |
|
Control Voltage Range |
+22V |
+28V |
|
Operating Temperature |
-25℃ |
+70℃ |
|
Storage Temperature |
-55℃ |
+85℃ |
Pin Descriptions:
Pin 1 to voltage(DC +22U-+28V),Pin15 to GND
|
Drive |
Standard drive voltage |
TTL drive voltage |
||
|
Pin 3 |
Pin 5 |
Pin 7 |
Pin 8 |
|
|
A(1to2;3to4) |
GND |
Open |
H |
L |
|
B(1to4; 2to3) |
Open |
GND |
L |
H |
Outline Drawing:
AV80104 (Unit: mm)
Ordering Information:
|
AV80104 |
DC-50GHz DPDT |
Notes:
1. The negative pole must always be connected to ground. if the negative pole is not connected to power supply ground, catastrophic failure will occur.
2. Before switching, microwave signal sources must be cut off.
3. Product specifications and descriptions in this document are subject to change without notice.
