Heavy Duty 10 Ton Pneumatic Air Winch with Air Cylinder Brake
- 1000 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | china coal | Place of Origin | China | |
| Model Number | JQHS100*20 |
Product Description
chinacoal11
we provide service of enterprise's customs declaration, inspection.
JQHS100*20 series air winch adopts compressed air as power to drag heavy cargo. They are very popular with construction sites, platform of oilfield off-shore and inland; drilling platforms,marines,mining,engineering sites to load and unload heavy cargo.
Advantages
1.Passed ISO9001:2008, CE, CCS, API verification.
2. Reliable operation with little noise.
3. Variable speed.
4.Stable in inflammable, explosive, wet, damp and other extremely operating conditions.
5. Hand and foot double brake.
6. High starting torque ensures it starting with load.
7.Over-load protection.
Technical Parameters
Pressure of Compressed Air 0.8 MPa
Rated Pull Force 10 Ton
Rated Cable Speed 20 m/min
Air Motor Normal Power 30 kW
Diameter of Cylinder 160 mm
Cylinder number 5 pcs
Air Consumption 0.4 m3/s
Drum Diameter 300 mm
Width 620 mm
Wheel Rim Diameter 660 mm
Wire Rope Storage 330 m
Wire Rope Diameter 19 mm
Configuration Length 1638 mm
Width 960 mm
Height 930 mm
Weight 1300 kg
