US$ 1.73/ - 1.73/
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
SunLink
Place of Origin:
China
Model Number:
120W 130W 140W Poly Panel
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
Brand Name
SunLink
Place of Origin
China
Model Number
120W 130W 140W Poly Panel
Place of Origin: China
Certification: IEC61215,Safety tested IEC61730,CE,TUV,MCS
Model No: SL120W,130W,140W Poly Panel
Brand Name: SunLink
Price:USD1.73/Wp CIF
Terms of Payment: T/T or L/C
Delivery time:10~25 days within
Warranty term: Product warranty 10 years;Power warranty 12 years above 90%,25 years above 80%
Supply Ability: 2MW/month
Minimum Order: 10pcs
Packing:4pcs/carton
Specifications:
NOCT:45 2℃
Voltage temperature coefficient(Voc):-0.36%/℃
Current temperature coefficient(Isc):+0.033%/℃
Power temperature coefficient(Pmpp):-0.5%/℃
Minimum power tolerance:5%
PV module with 140 maximum power
Cell: polycrystalline silicon solar cells 156 x 156mm
Frame: Anodized aluminium
Max. system voltage: 1,000V DC
Weight: 13kg
Dimensions: 1485 x 667x 35mm
Electrical characteristics: Max. power: 140WP
Nominal voltage(Vmp):18.0V
Nominal current(Imp):7.78A
Open circuit voltage (Voc): 22.4V
Short circuit current (Isc): 8.68A
Operating Temperature:-40 to +85℃
