Certification:CE,SGS
6000bph mineral water washing filling capping machine
Quick Detail:
1. Product: 6000bph mineral water washing filling capping machine
3. Main Material: SS304
4. Production capacity: 6000bph(500ml)
5. Usage: Fill pure/mineral/distilled water and so on
6. Dimension: 2450*1800*2200mm
7. Warranty: 1year free
Soda Washing Filling Capping Machine 4Kw With 6 pcs Capping Head
Description:
Main Features of 6000bph mineral water washing filling capping machine
1. Air Conveyor connectes with bottle-in starwheels. Bottle neck holding transferred.
2. Clamp transferring technology varied bottle types.
3. With little abrasion. Stable Transferring. Easy to change bottles.
4. With ring type pressure bearing hydraulic cylinder.
5. With high filling speed and exact liquid level.
6. Excellent Stainless Steel. Electric Components are of world known brand. All achieve national sanitary standard.
7. The bottle-out starwheel is of screwdown shape. No need to adjust transferring chain\'s height to different bottles.
8. Easy to operate and maintain.
9. PLC and transducers and othe main electric parts are of world famous brands, such as OMRON, MITSUBISHI etc.
Application:
This machine is designed for bottling non-air drinks, such as pure water, mineral water etc, it
integrates bottle washing, filling and capping into one monobloc unit.
Specifications:
Feature6000bph mineral water washing filling capping machine
1. This equipment is automatic washing filling capping three in one machine. It’s of many advantages, such as compact structure, perfect control system and easy to be operated. Advanced touch screen and PLC control system makes man-machine communication true.
2. Washing part is mainly composed of washing pump, bottle clamps, water distributor, up turn-plate, guide rail, protection cover, spraying device, defrosting tray, rinse water take and rinse water refluxing tank.
3. Filling Part is mainly composed of filling barrel, filling valves (normal temperature and normal pressure filling), filling pump, bottle hanging device / bottle pedestals, elevating device, liquid indicator, pressure gauge, vacuum pump, etc.
4. Capping part is mainly composed of capping heads, cap loader (separated), cap unscrambler, cap drop rail, pressure regular, cylinder and also we need an air compressor as the auxiliary external equipment.
5. Main electrical components are all imported from world famous brands to guarantee excellent performance of the whole machine.
2) Technical parameter
|
Model |
CGF18-18-6 |
|
Rinsing head |
18pcs |
|
liquid filling head |
18pcs |
|
Capping head |
6pcs |
|
Capacity |
6000bph (500ml calculate) 2000bph (1500ml) |
|
Washing pressure |
0.2-0.3Mpa |
|
Filling Temperature |
Room temperature |
|
Filling style |
Isobaric filling |
|
Compressed air |
0.5-0.6Mpa |
|
Water consumption |
1.5t/h(ex beverage water) |
|
PET bottle type |
Bottle dia.φ50-φ90mm Bottle height. φ160~φ340mm |
|
Suitable cap type |
screw cap |
|
Total power |
4KW |
|
Total weight |
3000kg |
|
(L×W×H)Overall Size |
2650×1900×2400mm |
3) Pictures:
Washing head
Filling head
Capping head
Competitive Advantage:
Jiayuan machinery co.,ltd is a professional manufacture of liquid packaging equipment.
1. T
