Professional Sheet Metal Roll Forming Machines / GI Corrugate Roof Forming Machine

Delivery Time:3-5 days
Certification:CE,FCC,MSDS

Professional Sheet Metal Roll Forming Machines / GI Corrugate Roof Forming Machine

Brief Introduction

GI Corrugate Roof forming machine  material thickness:0.2mm  feeding width: 762/925mm

Machine composition

5Ton*1250mm Hydraulic un-coiler Hydraulic system expand coil inner hole, Pump motor: 3KW Frequency Inverter to regulate turning speed, Motor: 2.2KW Link-connect expanding system Automatic stopping device, Load capacity = Max.5Tons Coil Inner-diameter= 510±30mm, Coil width = Max.1250mm Dance arm assistance for coil-turning speed control Manual Pre-shearing device (Un-powered)             Smart cut control, to cut off the end of the final piece of sheet only

Cold Rolling Mills

 Feeding section with guide;  Gear/Sprocket driving;23-step to form  Rollers manufactured from 40Cr, CNC lathes, hard Chrome Coated  Shafts Diameter=75mm, Precision Machined  Main motor =7.5 KW, Frequency speed control  Forming speed:Approx. 15m/min;  Protection Mesh Cover (full mesh type) Above Roll-former To Avoid Hands Go Inside

Hydraulic Cutting Device

Stop to cut, Post cut, No Blanking cut Pump motor =4.0KW Cutting tool material : Cr12, Heat treatment;

PLC Control System

Control the quantity & cutting length automatically; Combined with: PLC, Touch Screen (SIEMENS), Inverter (SCHNEIDER), Encoder (Omron), etc Cut-to-length tolerance≤±2 mm Control Voltage 24V Product Rack      Un-powered, 3 units

Packaging & Delivery

Packaging Details	40HC\'*1
Delivery Detail	45 DAYS

Machine Shows

Final Products Showroom
