Help CenterGroundnut Combine Harvester Self-propelled With 30hp Tractor
Related Products
Technical parameters:
Self-propelled:
Matched Power:30hp
Lose ratio: ≤1%
Working Efficiency:0.13-0.30 ha/h
Broken ratio: ≤1%
Weight:1750kg
Cleanness: ≥95%
Overall dimension:(LxWxH) 4300x1800x2250mm
Working width: ridge space 750mm-850mm
line spacce 180mm-250mm
Feature:
Peanut excavation,fruit picking,cleaning,storing,bagging process,
transportation once complete.
Using wheeled self-propelled,semi-fed-type pick,combine to enhance new technologies such as cleaning machine's performance so much better for most of the country cried croping patterns and soil conditions.
Peanut harvester | |
Model |
4HB-2A |
Type |
Self-propelled,semi-feed |
Weight |
1750kg |
Overall dimension |
|
Length |
3970mm |
Width |
1800mm |
Height |
2070mm |
Work efficiency |
0.13-0.3ha/h |
Fuel consumption |
22kg/ha |
Ground clearance |
280mm |
Min turn radius |
|
Turnleft |
3.7mm |
Turn right |
3.7mm |
Engine |
|
Model |
KM385B-214, Water cooling,4 stroke |
Rated power |
30hp |
Rated speed |
2350r/min |
Capacity of fuel tank |
27L |
Harvester |
|
Planter height |
350-450mm |
Harvester work width |
≤ 600mm |
Harvest Lines |
One ridge,two lines |
Height of discharge peanut |
600mm |
Type of discharge peanut |
Hydraulic tilting |
Capacity of peanut tank |
0.55m³ |
Gearbox |
Mechanical |
Driving wheel track |
1600mm |
Steering wheel track |
1550mm |
Wheelbase |
1778mm |
Tire |
|
Driving wheel |
750-16 |
Steering wheel |
450-14 |
Speed |
|
I |
2km/h |
II |
6km/h |
III |
7.5km/h |
IV |
9km/h |
V |
16km/h |
VI |
28km/h |
Reverse gear |
1.5-5km/h |
Hydraulic oil pump |
|
Model |
CBN314 |
Working pressure |
10Mpa |
Hydraulic steering gear |
|
Model |
BZZ-100 |
Working pressure |
10Mpa |
Harvester cylinder model |
YD40E |
Peanut tank cylinder model |
YS40E |
Steering cylinder model |
FT31F |
Hydraulic fuel tank capacity |
8L |
Hydraulic filter model |
0818B |
Battery model |
12V 6Q-65 |
