Energy saving indoor rgb 10mm led curtain display screen with Synchronization
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
- PPD539A102 Excitation communication controller Flexible configuration options are available
- 6ES7656-6CL33-1BF0 PLC module Supports complex control algorithms and data processing tasks
- 1394C-SJT22-A Servo controller Dc high precision power supply
- 9907-164 governor Monitor and adjust the speed of rotating machinery
- 3009X Communication module Supports multiple communication protocols
- H90QHQE013N0 The drive has a variety of configuration options and features
Product Details
Brand Name: | hm-led | Place of Origin: | China | Model Number: | HM-ID-P10-600 |
Product Description
p10 indoor vedio advertising led display screen
1.CE&Rohs
2.High clarity 10000dots/m2
3.Vivid color effect
4.Energy-saving
p10 indoor advertising led display screen
Item |
PH10 |
Pixel Pitch |
10mm |
Size of module |
160mmX160mm |
Resolution of module |
16 X 16 (dots) |
Density of pixel |
10000dots/m2 |
Pixel configuration |
1R1G1B |
Red wavelength |
625±2nm |
Green wavelength |
525±2nm |
Blue wavelength |
470±2nm |
Colors |
16777216 |
Best viewing distance |
≥10m |
Horizontal viewing angle |
140° |
Maximum power consumption |
1200w/m2 |
Brightness |
6500cd/m2 |
Gray scale |
14bits per color |
Color temperature |
6500k |
Control method |
Synchronization& Asychronization |
Driving method |
1/2scanning |
Frame frequency |
60Hz |
Refresh frequency |
≥300Hz |
Working Voltage |
AC220V/110V±10% |
IP grade |
IP65 |
Working temperature |
-20°C~+75°C |
MTBF |
More than 10000hours |
Life Span |
100,000hours |
