Indoor Steel Super Thin Led Display Sign Full Color for Shopping Center

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HJY		Place of Origin	China
Model Number	P10

Product Description

Indoor Steel Super thin led display sign full color for shopping center Specifications P10 indoor full color led display sign for shopping center
High resolution led display
Low power consumption
Competitive pric

P10 indoor led display

Indoor full color LED display could be used in indoor environment such as municipal mansion, enterprise hall, show room, cinema, stage, with various real-time signal sources and the SMD encapsulation technology, its purpose is to play the important news or events or TV program etc.

1) Super-thin and light cabinet can save room and time of installation.

2) High and adjustable brightness can meet the demands of the changing requirement of

customer in different environments.

3) No mosaic due to excellent flatness and nice uniformity of light-emitting
4) Wide viewing angles and the horizontal angle can reach 140° the images effect will not

change largely in the range.

5) High density make the images softer and vivider
6) Single-lamp maintenance with low cost.
7) Good heat dissipation capability because of the unique design of vent fan
8) Environmental-friendly and energy-saving

PLED-OF-10 Module Parameter
Dimensions(w*h)	160mm*160m	Resolution(W*H)	16×16
Pixel Pitch(mm)	10mm	Pixel Density	10000 Pixels/m2
Pixel Configuration	1R1G1B	Tual Pixel Density
PLED-OF-10 Cabinet Parameter
Dimensions(whd)	960mmx960mmx150mm	Max Power/m2	780W
Physical Resolution(w*h)	96x96	Module Quantity	36
Weight/Cabinet	62kg	Physical Pixels(total)	9216
Average Power/m2	260W	Material	Steel
PLED-OF-10 Display Parameter
Parameter	Value	Gray Scale	4096
Brightness(calibrating value)	≥6500	Weight	65kg/ m2
Red Wavelength(dominant)	623nm±1.5nm	Colors Capability	30bits
Green Wavelength(dominant)	525nm±1.5nm	Refresh Rate(PAL/NTSC)	1000HZ
Blue Wavelength(dominant)	470nm±1.5nm	Minimum Frame Rate	60HZ
Brightness(max/min)	1.1:1	Drive Type	Constant current drive
View Angle (min, 50% brightness)	Horizontal 160(+808-80)deg. Vertical 60(+308-30)	Scan Type	1/4 SCANING
Recommended Min. Viewing Distance	14	Control	Simultaneous with PC,pixel to pixel
Brightness Control	256	Input Voltage	AC220V/50Hertz or AC110V60Hertz
Date Transmission	UTP<100m, Multi-mode Optical Fiber <500m; Single-mode Optical Fiber<5000m	Color Temperature	Brightness of Red, Green and Blue adjustable by the software 100 grade. Color Temperature adjustable according to requirement
Digital Processing	12	Defects Rate	≤0.00001
MTBF	>10,000 hours	Life Span(50% Brightness)	>100,000 hours
Module Brightness Uniformity	<5%	Flatness
