6 gigabit LAN , 2 Optical fiber Firewall Security Appliance Supporting Wake-on-LAN

Delivery Time:3-5 days
Certification:CE,FCC,MSDS

Support LGA1155 Intel Core™ i3/i5/i7 Firewall Security Appliance six ethernet RJ45 LAN , two optical fiber , cisco standard COM ,2 groups of BYPASS 1U Rackmount server metal chassis

Quick detail

 Included 1U Rackmount server chassis +Motherboard+Power  Support LGA1155 Intel Core™ i3/i5/i7 32nm/22nm Processor  Using Intel® B75 Express Chipset  Dual-channel SO DDR3 1333/1066 memory slot, Max. up to 16GB  1* DB15 VGA port  Integrated 6* Intel 82574L 10/100/1000Mbps Ethernet  2* 10g Intel 82599 Optical fiber (2*Intel 82580DB for optional)  Supporting Wake-on-LAN and PXE function  LAN1~4 supports 2 groups of BYPASS function  Providing 1* Mini-PCIE slot, support WIFI/3G module  Providing a 3.5/2.5inch SATA disk location  1* MSATA slot, support SSD 6Gbps  1* CF card slot  1* COM(CISCO Standard Interface)  2* USB 2.0 port  6* LAN port  2* Fiber socket  ATX Power supply  1U chassis frame  Surface sandblasting oxidation process(Silver gray)  Dimension : 430mm(L)* 380mm(W)* 46.2mm(H)

The following configuration for choosing:

1UFWB75L6BO2-G1620208 : Included 1U Rackmount server chassis +Motherboard+Power +Intel Celeron G1620 cpu+2GB memory+8GB MSATA SSD   1UFWB75L6BO2-G2030216:Included 1U Rackmount server chassis +Motherboard+Power +Intel Celeron G2030 cpu(3.0G)+2GB memory+16GB MSATA SSD   1UFWB75L6BO2-I7432 : Included 1U Rackmount server chassis +Motherboard+Power +Intel i7-3770S cpu(3.1G)+4GB memory+32GB MSATA SSD   1UFWB75L6BO2-I33240216 :Included 1U Rackmount server chassis +Motherboard+Power +Intel i3-3240 cpu(3.4G)+2GB memory+16GB MSATA SSD   1UFWB75L6BO2-I33240432 : Included 1U Rackmount server chassis +Motherboard+Power +Intel i3-3240 cpu(3.4G)+4GB memory+32GB MSATA SSD

Appliance

Network security industrial firewall appliance firewall appliance Soft Router ROS / wayos appliance 6 LAN firewall


Specifications

CPU	Support LGA1155 Intel Core™ i3/i5/i7 32nm/22nm Processor
Chipset	Using Intel® B75 Express Chipset
Memory	Dual-channel SO DDR3 1333/1066 memory slot, Max. up to 16GB
Display port	1* DB15 VGA port
Network Function	Integrated 6* Intel 82574L 10/100/1000Mbps Ethernet
	2* Intel 82599 Gigabit Optical fiber (2*Intel 82580DB for optional)
	Supporting Wake-on-LAN and PXE function
	LAN1~4 supports 2 groups of BYPASS function
Wireless Network	Providing 1* Mini-PCIE slot, support WIFI/3G module
Storage	Providing a 3.5/2.5inch SATA disk location
	1* MSATA slot, support SSD 6Gbps
	1* CF card slot
Panel Port	1* COM(CISCO Standard Interface)
	2* USB 2.0 port
	6* LAN port
	2* Fiber socket
	1* POWER Switch
	1* POWER_LED, HDD_LED Indicator
	1* VGA port (Rear panel)
Cooling system	1* CPUFNA, 2* SYSFAN
Operating Temp.	-0°C~50°C
Storage Temp.	-20°C~70°C
Humidity	5%-95% (relative humidity; non-condensing)
Anti vibration	5~300Hz/random operating
Power	ATX Power supply
Installation	1U chassis frame
Material and Process	Surface sandblasting oxidation process
Size	430mm(L)* 380mm(W)* 46.2mm(H)
