Help CenterPLANT(INDUSTRIAL) FERMENTER : FMT PL Series
Related Products
< Features >
A graphic HMI program that is easy-to-use and a reliable PLX system have been adopted.
Through the use of an HMI program that is suitable for 21CFR PART 11, only approved users can change control variables.
The highest-level of credibility and safety are guaranteed through the use of the PLC system.
Pollution is prevented during a blackout. This product can work normally after a blackout by using a program to compensate for a blackout.
< Specifications >
+ High performance design
+ Vessel with water jacketed and insulation
(STS316L vessel + ST304 jacket)
+ Automatic sterilization
+ 700 ~ 500,000 L total volume or more
+ Top plate
- Inoculum port : Aseptic inoculation valve (option: Flaming)
- Pressure gauge and transmitter port
- Foam sensor port
- Exhaust port & condenser
- Agitation (top drive only)
- Light and spare ports
- Sight glass
- Manhole
+ Upper side wall
- 3 media port
- Gas overlay port and spare port
+ Lower side wall
- Sampling port
- Temperature, pH, DO sensor port and spare port
+ Bottom
- Harvest
- Agitation (bottom drive only)
+ Agitation
- Double mechanical seal
- High torque AC geared motor
- 4 baffles or more
+ Aeration
- Ring sparger (option : 1 ~ 10 micrometer micro sparger)
- 0.2 micrometer disposable hydrophobic filter with check valve
+ Impeller
- Rushton type/Pitched blade/Marine blade
+ Gas flow
- 1-TMFC + bypass rotameter
- Flow rate : max 1 vvm or more
- 2 or 3 TMFC (option)
< Contro l>
+ 17” touch screen computer
+ 1 to 255 vessels intelligent control
+ 16 control loop per vessel
+ Temperature control : PID control with water jacket heat exchanger(or heater) and circulation loop
+ pH control : acid/base agent
+ Agitation control : speed control
+ DO control : PID cascade control with agitation, feeding and gas flow rate
+ Antifoam control : antifoaming agent
+ Feed control : fed-batch control by time, DO, pH
+ Flow control : 1 ~ 4 mass flow control per vessel
+ 8 multi trend log data per vessel
+ Easily calibrated sensors
+ Level control : electrode type Hi/Low level control load cell type weight control(option)
+ Optional sensing unit : ORP, OD, 2nd pH, 2nd DO
