Battery Applications: Industrial portable device,medical device,miner lamp,etc.
Battery Features:
1. UN38.3,RoHS,CE certificated Li-polymer battery pack;
2. It could be customed by the clients' request,Li-ion Polymer Battery pack OEM orders are welcomed;
3. The anode materials is LiCoO2(Advantage: work voltage 4.2V-3.7V,charge/discharge voltage is stable,energy density is higher,cycle life is exceleent),the battery life cycles is over than 500 times and the capacity remains over 80% after 300 cycles;
5. Build in two-way protection IC circuit board, a single cell over charge protection voltage 4.20V±0.05V, over discharge protection voltage 2.7V±0.1V;
6. No memory effect, High voltage, high energy density, long cycle life;
7. Eco-friendly.
Battery Specifications:
| Cell | 3.7V 8400mAh FLP-725663 |
| Battery pack method | 1S3P of FLP-725663 |
| Norminal voltage | 3.7V |
| Nominal capacity | 8400mAh |
| Charge method | CC/CV |
| Standard charge | Constant charge current: 0.2C(1680mA) Constant charge voltage: 4.2V/Cell Charge cut off current: 100mA |
| Over charge | Detecrtion voltage: 4.250±0.050V |
| Release voltage: 4.150±0.050V | |
| Detection delay time: 1.0：±0.5S | |
| Over discharge | Detection voltage: 2.75±0.08V |
| Release voltage: 3.00±0.10V | |
| Detetion delay time: 100±50mS | |
Over discharge current | Over current: 6-8A |
| Delay time: 10.0±5.0mS | |
| Max. continuous discharge current | 5000mA |
| Discharge cut off voltage | 2.75V |
| Operating temperature | Charge: 0 ~ 45ºC |
| Discharge: -20 ~ 60ºC | |
Storge ambient temperature (charge 40-60%) | -20~60ºC less than 30 days |
| -20~45ºC less than 90 days; | |
| 20~20ºC less than 360 days | |
| Battery dimensions（Dia*H） | 23.5mm * 56.5mm*65.5mm |
| Weight | Approx. 170.0g |
