Energy Saving 94.05kw Industrial Dehumidifier 8500m/h , Low Dew Point Dehumidifier

Energy Saving 94.05kw Industrial Dehumidifier 8500m³/h , Low Dew Point Dehumidifier

Quick Detail:

Style: Double Wheel Adsorption

Desiccant Rotor: Sweden Proflute

Desiccant Rotor Material: Silica Gel and Molecular Sieve Composite Wheel

Rated Air Flow: 8500m³ /h

Supply Air Parameters: T=20℃ TL=-65℃

Dehumidifier Quality: High

Installed Power: 94.05kw

Voltage: 380V, 3 phase, 50Hz or as customer required

Certification: ISO9001:2008

Features: Economical, energy-saving

Usage: Air temperature and humidity control

Description:

ZCH-8500 High Efficiency Custom Built Low Dew Point Dehumidifier is for air deep drying, which is used for manufacturing spaces and processes that require extremely low humidity levels. It can supply air with dew point less than -60℃ to glove box for the production of lithium batteries.

Operating Principles:

Supply Air Stream

Outside air is drawn into the unit using the supply fan. The warm, moist outside air first passes through filters and then the cooling coil where it is cooled. The air then goes through the first desiccant wheel where the air is dehumidified and the temperature is raised.  After the medium cooling, the air is further dehumidified by the second desiccant wheel. At last the air is delivered directly to the space or into an existing air handler.

Exhaust Air Stream

Exhaust air is used to provide energy recovery for the desiccant wheel and is drawn into the unit using the exhaust fan. The air filtered and then heated and humidified during the energy recovery process. The air is then heated while passing through the regeneration coil. The heated air removes the moisture that the desiccant wheel adsorbs from the process air stream.

Applications:

Specifications:

Competitive Advantage:
