Brief Feature
1. Small factory lab production
2. Small size, flexible operation, easy adjustment
3. High filling accuracy
4. The filling head can be equipped from 6-10 under custom requirements
Detailed Product Description
Our STF series fillers are designed to dispense water like to medium thick products with small or medium filling volumes
Our STF series fillers are designed to dispense water like to medium thick products with small or medium filling volumes, especially suitable for lotions, oils, beverages, disinfectants, etc., and can be widely used in daily chemicals, food, pharmaceutical and other industries.
This series is based on the TIMED FLOW VOLUMETRIC FILLING PRINCIPLE and the filling process is driven by a centrifugal or magnetic pump. The machines are easy to operate and have high efficiency. You only need to aim the filling nozzles to the bottle mouths, press the manual bottom and the machine fills once as what you've set. The rigidity and consistency of the bottles are not required strictly. Additionally, our STF fillers have the following features: compact configuration, nice appearance, small size, easy adjustment, high filling accuracy and wide applicability. The number of filling nozzles can be equipped according to your requirements. All the features above make them ideal machines to be used in medium or small production scale.
Technical Specifications:
Voltage: AC 220V
Power: 0.1KW
Air Pressure: 0.5-0.6 Mpa
Air Consumption: 300L/min
Accuracy: ±1%
Filling Volume: 30~200ml
Filling Rate: 30~100bpm (With 6 filling nozzles)
Dimensions: L650mmxW260mmxH1800mm
