surface roughness tester

STANDARD: GB/T6062,ISO4278,DIN4768,JIS B,ANSI461

This instrument is compatible with four standards of ISO, DIN, ANSI and JIS and is widely used in production site to measure surface roughness of various machinery-processed parts, calculate corresponding parameters according to selected measuring condition sand clearly display all measurement parameters. When measuring the roughness of a surface, the sensor is placed on the surface and then uniformly slides along the surface by driving the mechanism inside the tester. The sensor gets the surface roughness by the sharp built-in probe. This roughness causes displacement of the probe which results in change of inductive amount of induction coils so as to generate analogue signal, which is in proportion to the surface roughness at output end of phase-sensitive rectifier. The exclusive DSP processes and calculates and then outputs the measurement results on LCD.

* Very easy to operate                         * Multiple parameter measurement: Ra, Rz

* Highly sophisticated inductance sensor         * Built-in lithium ion rechargeable battery and control circuit with high capacity               * Small in size, light in weight and easy to use

* Can communicate with PC computer for statistics, printing and analyzing by the optional cable and the software for RS232C interface.

*Manual or automatic shut down. The tester can be switched off by pressing the Power key at any time. On the other hand, the tester will power itself off about 5 minutes after the last key operation.

2.SPECIFICATIONS

Display: 4 digits, 10 mm LCD, with blue backlight

Parameters:  Ra, Rz

Display Range Ra:   0.05-10.00um/1.000-400.0uinch  Rz:   0.020-100.0um/0.780-4000uinch

Accuracy: Not more than 10%

Fluctuation of display value: Not more than 6%

Sensor: Test Principle: Inductance type        Radius of Probe Pin: 10um

         Material of Probe Pin: Diamond     Measurement Force of Probe: 16mN(1.6gf)

         Probe Angle: 90°                 Vertical Radius of Guiding Head: 48mm

Maximum driving stroke: 17.5mm/0.7inch  Cutoff length (l): 0.25mm /0.8mm /2.5mm  optional

Evaluation length:  1~5 cut off  optional

Resolution : 0.001μm    if reading <10μm

                      0.01μm    if 10μm≤reading<100μm

                      0.1μm    if reading ≥100μm

Power Li-ion battery: rechargeable

Attachment:

Standard Sensor RP-100             Groove Stylus SRP-110      curvature Probe SRP-120

Extension Rod   SER-150          Measurement Stand   SRS-1    Bluetooth interface

Standard Sample Plate    SSP-180       Cable and Software for RS-232/USB
