Low Speed Large-intermediate Drawing Machine With Annealing

Low Speed Large-intermediate Drawing Machine With Annealing thumbnail-1
Low Speed Large-intermediate Drawing Machine With Annealing photo-1
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
BAOC
Place of Origin:
China
Model Number:
BAOC-11D/300T
Contact Supplier Request Quote Chat Now
Wuxi Baochuan Machinery Company
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name BAOC
Place of Origin China
Model Number BAOC-11D/300T

Machine type

BAOC-11D/300T

Wire finished

Ø2.6-Ø3.2mm

Wire inlet

Ø1.0-Ø2.8mm

Drawing speed

450mpm/max

Dies No.

11

Slip ratio of m/c

19%+12%

frame

welded by steel plate

capstan

Tungsten carbide

Capstan dia.(Max.)

Ø350mm

Fix speed capstan dia.

Ø300mm

Bobbin loading& unloading type

Shaft type

Max.loading capacity

200KG/Max

Annealing method

DC.three-section annealing

Main motor

30 kw

Spool motor

7.5 kw

Transmission type

By gear

Tension control

By air pressure adjust

Traversing unit

Weight balance type

Detecting device

Magnetic brake

Max annealing current

DC2000A

Max annealing voltage

DC65V

Annealing wheel dia.

Ø300mm

Annealing length

3500mm

Annealing power

95KVA

Capacity of compressed air

0.4-0.6MPa,15L/min

Power source

380V 50/60HZ

Machine dimension

2100*1600*1700

Machine weight

3000KG
