8M IR Outdoor CCD Bus Reversing Camera
Image Pick-up device 1/3" COLOR CCD
Horizontal Resolution 420 TV Lines
Usable Illumination 0Lux (F:1.2) with 12 IR LED
Water resistance IP67~68
Electronic Shutter Time Auto:NTSC 1/60-1/100,000Sec,
Storage Temperature -20-- +60 RH 95% Max
The lens focal length and angle 2.1mm 150°
Scanning System NTSC 525 Lines, 60Field/Sec
Power Supply DC12V±10%,250mA
Size L70mm/W45mm/D45mm
Night vision available
Day / Night sensor for automatic adjustment
2) Image device: Sharp
4) Effective pixels: 512 x 582 pixels / 512 x 492 pixels
6) Scanning system: 2:1 interlace
8) Resolution: 420TV lines
10) Horizontal sync. frequency: 15.625kHz / 15.734kHz
12) Video output: 1.0Vp-p, 75 ohms
14) AGC: auto
16) White balance: auto
18) BLC: auto
20) Power supply: DC12V
22) Storage temperature: -40 ~ 85oC, RH 95% max.
24) Lens angle: 92o
2) Image device: Sharp
4) Effective pixels: 512 x 582 pixels / 512 x 492 pixels
6) Scanning system: 2:1 interlace
8) Resolution: 420TV lines
10) Horizontal sync. frequency: 15.625kHz / 15.734kHz
12) Video output: 1.0Vp-p, 75 ohms
14) AGC: auto
16) White balance: auto
18) BLC: auto
20) Power supply: DC12V
22) Storage temperature: -40 ~ 85oC, RH 95% max.
24) Lens angle: 69o
