Home > Manufacturing & Processing Machinery > Plastic Machinery > Injection Molding Machine > PVC Injection Machine DKM500 Dakumar-m
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
dakumar，sino
Place of Origin:
China
Model Number:
DKM500
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
PVC Injection Machine(DKM650) Dakumar-mNegotiableMOQ: 1 Set -
PET Injection Machine DKM650 Dakumar-mNegotiableMOQ: 1 Set
-
PET Injection Machine DKM500 Dakumar-mNegotiableMOQ: 1 Set
-
Pump Injection Machine DKM268H Dakumar-mNegotiableMOQ: 1 Set
-
Pump Injection Machine DKM330H Dakumar-mNegotiableMOQ: 1 Set
Brand Name
dakumar，sino
Place of Origin
China
Model Number
DKM500
DKM500 PVC Injection Machine
DKM500 PVC Injection Machine PLATEN DIMENSION MACHINE DIMENSIONS DKM500 PVC Injection Machine dakumar Injection Molding Machine DKM500 Parameters A B C Injection Unit Screw Diameter mm 80 90 100 Theoretical shot Volume cm 3 2196 2780 3432 S
DKM500 PVC Injection Machine
PLATEN DIMENSION
MACHINE DIMENSIONS
| DKM500 PVC Injection Machine | |||||
| dakumar Injection Molding Machine DKM500 Parameters | A | B | C | ||
| Injection Unit | Screw Diameter | mm |
80
|
90
|
100
|
| Theoretical shot Volume | cm3 |
2196
|
2780
|
3432
|
|
| Shot Weight(PVC) | g |
2635
|
3335
|
4118
|
|
| oz |
93
|
117.6
|
145
|
||
| Length/Diameter ratio | L/D |
23.6
|
21
|
18.9
|
|
| Injection pressure | kg/cm2 |
1797
|
1420
|
1150
|
|
| Injection rate | cm3/s |
464
|
588
|
725
|
|
| Injection stroke | mm |
437
|
|||
| Screw speed | rpm |
0~155
|
|||
| Plasticizing Capacity(PVC) | kg/hr |
415
|
536
|
680
|
|
| Clamping Unit | Clamping Tonnage | Ton |
500
|
||
| Max. daylight | mm |
1590
|
|||
| Clamping Stroke | mm |
740
|
|||
| Distance Between Tie-Bars | mm |
800x800
|
|||
| Min. mould dimension | mm |
560x560
|
|||
| Mould thickness range | mm |
350~850
|
|||
| Ejector force | KN |
150
|
|||
| Ejector stroke | mm |
200
|
|||
| No.of ejector pins | unit |
13
|
|||
| Others | Major motor | hp/kw |
75/55
|
||
| System pressure | kg/cm2 |
160
|
|||
| Hydraulic pump capacity | L/min |
314
|
|||
| No.of heater zones | unit |
5+1
|
|||
| Heater power | kw |
25.9
|
|||
| Machine weight | Ton |
22.5
|
|||
| Tank capacity | L |
1050
|
|||
