P5 Indoor SMD LED Screen Panel for Rental Use

FOB Price

Negotiable / Piece

6 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	SZADDTECH		Place of Origin	China
Model Number	PH 5mm

High Definition LED Screen (P5mm SMD Model )
Technical Specifications
LED Lamp Parameters
No.	Item	Specifications
1	LED lamps	SMD 3528
LED Module Specifications
1	Pixel Pitch	5mm
2	Pixel Configuration	RGB (SMD 3 IN 1 )
3	Module Resolution	32 x 32 pixel dots
4	Module Size	160mm x 160mm
LED Cabinet Specifications ( Standard Cabinet )
1	Cabinet Size(WxH)	640mm x 640mm
2	Cabinet Resolution	128 x 128 pixel dots
3	Module Quanity	16 PCS
4	Cabinet Frame Material	black powder coated steel(Aluminum for option)
5	Cabinet Weight	18 Kg
LED Screen Parameters
1	LED Screen Resolution	40,000 dots/㎡
2	LED Screen Brightness	2000 nits
3	Brightness Adjustment	manually by software
4	Driving Method	constant current 1/16
5	View Angle	Horizontal 120° Vertical 120°
6	Optimum Viewing Distance	>4 meters
7	Refreshing Frequency	1000 Hz
8	Greyscale	4096 grades
9	Displaying Colors	69 billion
10	Input Voltage	Full range : 110-240 V AC , 50/60 Hz
11	Power Consumption	Max.: 1000 W/㎡ Average: 400-800 W/㎡
12	Defects Rate	≤0.00001
13	MTBF	>5000 hours
14	Lifespan	≥100,000 hours
15	Protection Grade	IP43
