LED Stage Background Full Color LED Display
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
ADDTECH
Place of Origin:
China
Model Number:
P6
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
Brand Name
ADDTECH
Place of Origin
China
Model Number
P6
| P6 Indoor SMD LED Full color Video Display | |||
| Technical Specifications | |||
| LED Lamp Parameters | |||
| No. | Item | Specifications | |
| 1 | LED lamps | SMD 0603 | |
| 2 | Wavelength | Red LEDs | 628-630nm |
| Green LEDs | 520-525nm | ||
| Blue LEDs | 465-470nm | ||
| LED Module Specifications | |||
| 1 | Pixel Pitch | 6mm | |
| 2 | Pixel Configuration | 1R1G1B (SMD 3 IN 1 ) | |
| 3 | Module Resolution | 32dots X 16dots | |
| 4 | Module Size | 192mm x 96mm | |
| LED Cabinet Specifications ( Standard Cabinet ) | |||
| 1 | Cabinet Size(WxH) | 960mm x 768mm | |
| 2 | Cabinet Resolution | 160x128 pixel dots | |
| 3 | Module Quanity | 40 PCS | |
| 4 | Cabinet Frame Material | black powder coated steel | |
| 5 | Cabinet Weight | 33Kg | |
| Screen Parameters | |||
| 1 | Screen Resolution | 27,777 dots/㎡ | |
| 2 | Screen Brightness | 5000 nits | |
| 3 | Brightness Adjustment | manually | |
| 4 | Driving Method | constant current 1/8 | |
| 5 | View Angle | Horizontal 120° Vertical 120° | |
| 6 | Optimum Viewing Distance | >5m | |
| 7 | Refreshing Frequency | ≥180Hz | |
| 8 | Input Voltage | AC220V/50Hz or AC110V/60Hz | |
| 9 | Power Consumption | Max.: 1200 W/㎡ Average: 400-800 W/㎡ | |
| 10 | Defects Rate | ≤0.00001 | |
| 11 | MTBF | >5000 hours | |
| 12 | Lifespan | ≥100,000 hours | |
| 13 | Protection Grade | IP43 | |
| 14 | Temperature-operating | ﹣20℃~+60℃ | |
| 15 | Humidity-operating | 10%~95% | |
| 16 | Operating System | Windows98/me/2000/NT/XP | |
| Packaging Details | |||
| 1 | packing material | wooden box or flight case | |
| 2 | screen weight | 45Kg/㎡ | |
| 3 | packing way | one case holds one or two cabinets |
