PLC Control 2 - 4m/min Hydraulic Punching Roll Forming Equipment Solar Strut 13 Roller Stations
Solar Strut Technical Parameter
1. Steel Sheet Thickness: 1.5-2.0mm (depend on requirement )
2. Hydraulic power: 5.5Kw
3. Transmission way: 1.5 inch single chain
4. Material of blad: Cr12, quenching treatment
5. Capacity of Decoiler: 3 ton manual decoiler
6. Forming Speed: 12m/min (not include cutting and punching stop time)
7. Max speed: 4-5m/min (include cutting and punching stop time)
8. Roller Groups: 13 stations
9. Roller Material: GCr15 grade steel, quenching treatment
10. Material: galvanized steel or black sheet
11. Principal Axis: 45# high grade steel with quenching treatment
12. Main Motor Power: 7.5 Kw
Solar Strut Main Components
| S.N |
Equipment name |
Quantity |
| 1. |
3T manual un-coiler |
1 set |
| 2. |
Feeding and leveling device |
1 set |
| 5. | Main roll forming machine 13 stations drived by single chain | 1 set |
| 6. |
Hydraulic station |
1 set |
| 7. |
Control system (including control box) |
1 set |
| 8. |
Out tables |
2 sets |
| 9. |
Spare parts |
1 package |
| 10. |
Cutting dies |
2 sets |
| 11. |
Punching die set |
2 sets |
Advantage for Solar Strut
1. Reasonable Price
2. High Quality
3. 12 Months Warranty
4. More Than 10 Years Experience
5. Durable
6. Reliable
Working Flow of Solar Strut
Decoiler----Feeding and Leveling---Roll forming---Hydraulic punching---Cutting---Run out table
Profiles of Solar Strut
Company Introduction
Wuxi Suhang Machinery manufacturing Co., Ltd. is a comprehensive enterprise integrating production, sales and services. We are mainly engaged in providing machineries and equipment. Owing to a professional teamwork, we are experienced in manufacturing, import and export, customers\' design, installation and test, technical solution and after-sale services. We have shipped out our machines to more than 50 countries, and keep good business relationships with a large amount of worthy customers, contributing to our great business records and reputation.
Customes Visiting
Loading Pics
