Blue 220mm Profile Width Roll Forming Machinery For Door Frame
Technical Parameter
1. Materials to form door frame: According to the customers’ requirement1.5-2.0mm steel
2. Work speed: 3-15m/min
3. Forming steps: About 18 steps
4. Material of rollers: GCr15 steel, precision-machined, high frequency quenching HRC58-62
5. Material of main shaft : 45# high quality steel
6. Chains’ material: 45# steel, high frequency quenching, circular pitch: 38.1; number of teeth: 13
7. Main motor power: 11KW8
9. Electronic control: PLC control
10.Dimension of main machine: About 8000mmX800mmX800mm
11.Weight: About 5T
12.Drive system: Chain drive
13.Total power: 10.5kw
Working Flow
De-coiler—→level device—→main forming machine—→straightening—→hydraulic Punching —→hydraulic cutting—→ run out table
Machine Componnets
| Name | Quantity( set) |
| Decoiler | 1 |
| Level device | 1 |
| Main forming machine | 1 |
| Hydraulic punching | 1 |
| Hydraulic cutting machine | 1 |
| Cutting blades | 5 |
| Straightening | 1 |
| PLC Control Panel | 1 |
| Run out table | 2 |
Machine photo
