PCB UHF Metal Tag, 860960MHz Small Metal Tag for IT Assets Management, 52132.7mm

PCB  UHF Metal Tag, 860～960MHz Small Metal Tag for IT Assets Management, 52×13×2.7mm

Physical Features:

Product Model: RCP8004

Material: FR-4

Dimensions: 52×13×2.7mm

Weight: 4.2g

Color: Black (optional)

Working Temperature: -40℃～150℃

RFID Features:

Protocol: EPC C1G2 (ISO18000-6C)

Frequency: 860～960MHz

Chip: Alien Higgs 3 (optional)

EPC Memory: 96 bits, maximum 480 bits

User Memory: 512 bits

Read Range: Stationary reader: Over 4m (30dBm)

                    Handheld reader: Over 2m (28dBm)

Other Features:

Environmental: ROHS compliant

Data storage: >10 years

Re-write: 100,000 times

Fixture: 3M adhesive or rivet

Customization: Company logo print

Introduction:

This tag is designed on wave-absorbing material. It solves the problem that tags can not be attached to metal surface(Reading distance even will be father when it is attached to metal surface). At the same time, it can work outside in the hard environment. It complaints with EPC C1G2 (ISO18000-6C), operating frequency is 860～960MHz (It can be used worldwide). Each tag has a unique ID and stores user data.

Application:

IT asset management, fixed assets management, automotive component tracking, industrial manufacturing, etc.
