SC LC Fiber Optic Patch Cord 2.0mm Anti rodent / Harsh Environment fiber optic jumper

SC LC Fiber Optic Patch Cord 2.0mm Anti rodent / Harsh Environment fiber optic jumper​

FOC COMMUNICATION CO., LTD  is the professional manufacture of fiber optic components. We produce the whole series fiber optic patc cord, including breakout cable patch cord, ribbon fan out patch cord, indoor armored patch cord, outdoor armored patch cord, waterproof patch cord, OM3 and OM4 patch cord.

Fiber Optic Patch Cord is one piece of cable with connectors in both sides. If only one side assemble the connector, it is called fiber optic pigtail.
Cores: simplex, duplex, multi core patch cords.
Cable Jacket: PVC, LSZH, OFNR, OFNP
Cable outer diameter: 0.9mm, 2.0mm, 3.0mm
Fiber Type: SM(9/125um), OM1(62.5/125um), OM2(50/125um), OM3, OM4
Connector Type: FC, SC, ST, LC, MU, MTRJ, MPO, E2000, SMA, FDDI, D4, DIN
Endface type: UPC, APC

Descriptions
Armored fiber optic patch cord are used in indoor applications in customer premises, central offices and in harsh environments. The patch cord provide flexible interconnection to active equipment, passive optical devices and cross-connects. Armored patch cord are constructed with a stainless steel tube over a standard patch cord surrounded by a stainless steel mesh with an outer jacket. They are terminated with standard range of connectors, all quality tested to international standards.

Features
Conform to IEC, IEA-TIA, and Telecordia performance requirements
Easy installation
Available in different fiber types
Available in standard and custom length
RoHS compliant

Applications
Telecommunication Networks
CATV
LAN and WAN
FTTX
Broadband network
Military application

SPECIFICATIONS


Technical Test Data

Rema   Remark: The load bend and load torsion not suitable for 0.9mm patch cord or pigtail.

Order   Ordering information
