Certification:ISO 9001 And Manufacture License Of Pressure Tube
U Type Welded SS Tubes For Feedwater Heater With AISI 304 / AISI 316L
Quick detail:
① Material Grade: AISI 304 / AISI 316L
② Item:U Type Welded SS Tubes
③ Brand: KORER
④ Standard: ASME SA249 / ASME SA688
⑤ Delivery Condition: Anneal Or Pickled
⑥Application:Feedwater Heater
Description:
Material Chemical Coposition:
|
Grade |
Chemical Composition(%) |
Remark |
|||||||||
|
C≤ |
Mn≤ |
P≤ |
S≤ |
Si≤ |
Cr |
Ni |
Mo |
N |
Cu |
||
|
304 |
0.08 |
2.00 |
0.045 |
0.030 |
0.75 |
18.0~20.0 |
8.0~10.50 |
0~0.1 |
|||
|
304L |
0.030 |
2.00 |
0.045 |
0.030 |
0.75 |
18.0~20.0 |
8.0~12.0 |
0~0.1 |
|||
|
321 |
0.08 |
2.00 |
0.045 |
0.030 |
0.75 |
17.0~19.0 |
9.0~12.0 |
0~0.1 |
Ti≥5×(C+N),≤0.70 |
||
|
316 |
0.08 |
2.00 |
0.045 |
0.030 |
0.75 |
16.0~18.0 |
10.0~14.0 |
2.0~3.0 |
0~0.1 |
||
|
316L |
0.030 |
2.00 |
0.045 |
0.030 |
0.75 |
16.0~18.0 |
10.0~14.0 |
2.0~3.0 |
0~0.1 |
||
|
317 |
0.08 |
2.00 |
0.045 |
0.030 |
0.75 |
18.0~20.0 |
11.0~15.0 |
3.0~4.0 |
0~0.1 |
||
|
317L |
0.030 |
2.00 |
0.045 |
0.030 |
0.75 |
18.0~20.0 |
11.0~15.0 |
3.0~4.0 |
0~0.1 |
Applications:
|
Industry |
Applications |
Industry |
Applications |
|
|
Thermal Power Station |
Condensers |
Paper / Pulp |
Industrial Equipments |
|
|
Nuclear Power Staition |
Condensers |
Engineering |
Machineries Instrumentation Tubing |
|
|
Chemical |
Heat Exchanger, Pressure Vessels |
Sugar |
Evaporators, Condensers, Driers |
|
|
Petrochemical Industry |
Condensers, Heat Exchanger |
Automobiles |
Muffler Tubes, Hydraulic Tubing,Exaust Pipes, Bracket Tubes |
|
|
Refineries |
General Piping |
Architectural Construction |
Construction |
|
|
Fertilizers |
Press |
