Features include:
1.Versatile.Could be applied to gravel pile,sand pile,sheet pile and so on.
2.An ideal piling equipment for bridge,port,railway,road's construction work.
3.Easy operate ,make your work much more easier and efficient.
The high frequency hydraulic vibratory hammer produced by our company is used together with the excavator to effectively utilize the hydraulic power of the excavator and fully bring the strong motility of the excavator into play. Depending on the flexible operation, the construction of the pile foundation engineering steps into a new stage and it greatly saves the construction cost, improves work efficiency, realizes several purposes of your excavator, and promote the investment benefit. It is especially valuable for the short and medium pile work of municipal government, bridge, railway, lake and cofferdam, and construction site and is suitable for driving and extracting flat sheet pile, channel steel, I-steel, cement square pile, cylinder pile, and Larsen piles in various shapes.
Operating range:
a. Depending on different fixtures, it can drive and extract steel sheet pile, cement pile, rail pile, iron plate, H steel and steel pipe, etc.
b. It is suitable for the construction engineering like water channel improvement and bearing platform construction.
c. It can be operated frequently near to the building and does not damage the building.
d. Through adopting German gear technology, it features quite operation and short construction period to solve the problems related to environmental protection.
e. Featuring simple operation, the pile-holding and driving & extracting operation can be finished by the driver himself.
Specifications
|
model item |
KX-300 |
KX-350 |
KX-450 |
KX-550 |
|
Vibratory speed(r/min) |
2800 |
2700 |
2600 |
2400 |
|
Max.extracting force(tons) |
45 |
60 |
75 |
90 |
|
Operating force of oil hydraulic system |
280bar |
|||
|
flow demand of oil hydraulic system |
180LPM |
230LPM |
280LPM |
320LPM |
|
clamping power for clamping cylinder |
40T |
40T |
40T |
40T |
|
BUFFER blocks number |
12 |
14 |
16 |
18 |
|
Whole weight |
1350kg |
1400kg |
1500kg |
1650kg |
|
Clamping system weight |
400kg |
400kg |
400kg |
400kg |
|
Model and weight for assistant arm |
A200/500kg |
A270/618kg |
A300/700kg |
A300/700kg |
|
Fit for extractor operating weight |
24~30 tons |
30~40tons |
40~50tons |
50~60tons |
|
Depth for pile driving(M) |
5--10 |
6--12 |
7--16 |
7--18 |
