IP65 Occupancy Detect Microwave Motion Sensor MC025S 220-240vAC 400w Plastic For Office Classroom Application
Description
1. Thanks to occupancy detection design, any slight motion such as typing on keyboard or taking note will be detected.
2. Idea sensor for office and classroom application .
3. With Mini sensor detector ,IP 65 approval ..
4. Zero-crossing point operation helps protect the sensor against in-rush current.
5. 5.8GHz high frequency microwave(C-Band license-free operation)
6. 4-pole press-in terminal (L, N,N,L′),easy assembly.
7. Detection area, time delay and daylight threshold can be precisely set via DIP switch.
8. MC025S is an innovative motion sensor, switch on the light on detection of movement, and switch
off a hold time when there is no motion detected. As built-in daylight sensor can read brightness
value, the sensor does not switch on the light if with sufficient in natural light.
Function:
ON-OFF function
Specifications:
|
Operating voltage |
220-240Vac, 50Hz |
|
Rated load |
400W(inductive), 800W (resistive) |
|
HF system |
5.8GHz±75MHz, ISM wave band |
|
Power consumption |
≤0.5W(standby), <1W(operation) |
|
Transmitting power |
<0.5mW |
|
Detection zone Max.(D x H) |
8m x 3m |
|
Motion detection |
0.5~3m/s |
|
Detection angle |
150°(wall installation) 360°(ceiling installation) |
|
IP rating |
IP65 |
|
Operation temperature |
-20℃~60℃ |
|
Hold time |
10s/30s/90s/3min/20min/30min |
|
Sensor model |
＞4m ,Movement detect ,≤4m ,Occpancy detect |
|
Daylight sensor |
5lux / 15lux / 30lux / 50lux / Disable |
|
Life time |
50,000 hours |
|
Guaranty |
5 years |
Applications:
MC025S is perfect solution for office and classroom application thanks to it\'s occpancy sensor detect
