0 - 10V Dimmable LED Tri-proof Light Fixed or Suspended Installed 600mm IP65
Description:
IP 65 Tri-proof Lighting Fixtures are used in places where the light source is sealed form the outside elements like water and dirt. It creates high illumination while providing a washdown capability.This is especially needed in food service lighting, agricultural lighting, laboratory, industrial and other places where need light not be compromised by the surrounding environment. The is made of PC which means it won’t turn yellow like less inexpensive forms of plastic.
Specifications:
| Item No. | ALS-TRI12 |
| Dimension | 600*91*74mm |
| Power | 20W |
| Light Source | SMD2835 |
| LED Qty | 120pcs |
| Luminous Flux | 1700~2200lm |
| Luminous Efficiency | 95-110lm/W |
| Input Voltage | AC85-135V, AC185-265V |
| Forwarder Current | 50-55mA |
| Working Frequency | 50/60Hz |
| Body Material | AL housing+PC cover+Aluminum board |
| Beam Angle | 180° |
| CRI | 80-85 |
| Power Factor | >0.95 |
| Color Temp. | WW: 3000-3500K,4000-4500K PW: 4500-5000K, 5000-5500K, 5500-6000K CW:>6000K |
| Working Temp. | -20~45℃ |
| Waterproof Level | IP65 |
| Working Lifetime | 30,000 hours |
| Warranty | 5 years |
| Certificate | CE,RoHS,TUV |
| Packing | Carton Size: 680*260*300mm 6pcs/carton N.W.: 7kg G.W.: 10kg |
Features:
1. This product meets the standard of CE, Rohs and TUV certification.
2. Water-proof design without adhesive, so there is no water leakage caused by adhesive aging, convenient to disassemble.
3. Light panel and PSU adopt modular design,connected via terminals, easy and convenient to maintain, no need of soldering.
4. Energy saving and eco-friendly, no IR or UV ,no mercury contamination, RoHS compliant.
5. Aluminum profile+PC, high impact resistance, good waterproof and anti-aging performance.
6. High transmittance PC cover transmit soft light+small power LEDs, high light efficiency ,uniform light ;no dark spot.
7. High efficient heat dissipation, LEDs and power supply low temperature rise ,high stability of continuous working.
8. Can switch start frequently, no flicker and flare ,good color rendering performance. Compact appearance, novel design style, easy to install and transport.
Applications:
Suitable for corrosive strong, dusty areas, Industrial lighting demand places, such as: Iron and steel, ships, railway, electric power, metallurgy, petrochemical and all kinds of factory, workshop, places and large facilities, venues and other places.
