Black Grey White PET and Nylon Braided Expandable Sleeving for Automobile , AC Motor , Heater

Delivery Time:5-8 working days
Certification:UL, ROHS, REACH

Black Grey White PET and Nylon Braided Expandable Sleeving for Automobile , AC Motor , Heater

Model number:SB-ES

Working temperature: -50ºC ～ +150ºC

Melting point:  250ºC±5   Flame resistant grade: UL VW-1

Structure

Expandable sleeving is braided by environment-friendly polyester monofil. (PET, PA6, PA66,PPS), It possesses good flexibility, fire resistance, abrasive resistance and thermal insulation performance. The sleeving owns smooth surface, bright color, various patterns.

Usage & Main Parameters

Expandable sleeving is widely used in bounding and protecting of electrical cables, automobile and aviation sectors.

The selection of this product refers to following four parameters.

A- yarn number (one or three);

B- Diameter of single yarn (0.25mm or 0.20mm)

C- Strand number (48 spindles braiding machine or 72 spindles braiding machine)    D- flat width(6mm or 18mm)

Dimension

Part No.	Model No.	Min width (mm)	Max width(mm)	Part No.	Model No.	Min width(mm)	Max width (mm)
24#	120024	3	6	56#	120056	8	16
125024	3	6	125056	8	16
320024	4	8	320056	10	20
325024	4	8	325056	10	20
32#	120032	4	8	64#	120064	9	18
125032	4	8	125064	9	18
320032	5	10	320064	12	24
325032	5	10	325064	12	24
36#	120036	5	10	72#	120072	10	12
125036	5	10	125072	10	12
320036	6	12	320072	15	30
325036	6	12	325072	15	30
40#	120040	6	12	96#	120096	12	24
125040	6	12	125096	12	24
320040	7	14	320096	20	40
325040	7	14	325096	25	50
48#
