DAILY NECESSITIES HARD PAPER AND PVC BLISTER PACKING MACHINES

Delivery Time:50 working days after received your payment
Certification:ISO9001

DZP-320 Medicine Paper and PVC Blister Packing Machine For Daily Necessities

Specifications

Item Model	DPZ-320
Max. Cutting Speed	25times/min
Max. Forming Area	250*160(mm)
Max. Paper-card Size	320*200(mm)(200g-700g)
Adjustable Pulling Length	40-160(mm)
Max. Forming Depth	40(mm)
Power	380v  50Hz  9kw
Air Compression	≥0.25m3/min
Overall Dimension(L*W*H)	4800*600*2000(mm)
Weight	1500kg

Description

Uses the frequency conversion velocity modulation, touch screen (HMI) and the PLC programmable control system, a high degree of automation, operating more clear and simple. Step controlled by servo motor trips, easy to adjust travel scope, and convenient to change mold. Photoelectric control, the machine will beep alarm automatically while lack of PVC or paper card. The machine can be divided into three parts for easier transportation and movement.  Comply with the GMP requirements of the pharmaceutical with smooth appearance and easily to be cleaned. According to the customers’ requirements, we can design new molds and automatic feeders for different packaging object.

Applications

The machine adopts frequency control of motor speed. Collecting machine, electricity, photo, air to integrate. And innovative design, manufacture according to National Standard strictly. Flexible stroke, modularize station structure, easy operate, high output, low noise, and equipped with beautiful out looking. machine is the ideal packing machine. machine main device including PVC heating, blister forming, blister detection(optional), products feeding, products lack detection.(optional), stroke pulling, punching, transporting, heating & sealing, etc.The PVC formed after heating and being soften in the forming mould. The blister fed product via blister detection device then into the punching device to make the single blister with product. After then, the blister delivered to heating and sealing device. At last, the finished products sent out to next procedure. All the devices work synchronously. The blister forming and products deeding equipped with the sensor in case of the bad blister and lack of products in blisters. Waste products rejected out via waste products exit.
