Help CenterHG406 Pipe Production Line
Related Products
I.Brief introduction
HG 406 high frequency longitudinal welded pipe production line / pipe making machine / tube forming machine is designed to produce welded pipes of 219mm-406mm in OD and 6.0mm-16.0mm in wall thickness, as well as corresponding square and rectangle tube.
II. Basic Technical Information:
1.Specification of pipes
Pipe OD: 219mm-406mm Thickness: 6.0mm-16.0mm
Square & rectangle tube: 130mm×130mm – 330mm×330mm, Thickness: 6.0mm-16.0mm
Length: 6 -12m Length Tolerance: ±3mm
2.Raw Material:
Material: Carbon steel coil
Width: 520mm-1340mm Thickness: 6.0mm-16.0mm
Coil ID:580-760mm
Coil OD: Max 2300mm
Coil Weight: 35t
3. Tube mill
Production Speed : 30 m/min
Direction : left to right or right to left from operator`s side decided by customers.
Electricity Input Power : 2900 kw
Line Area : 190m(length) ×17m (width)
Tube Bottom Passline (Above floor level) : 1200 mm
4, Table
|
Model |
Specification(mm) |
Thickness (mm) |
Electricity Input Power(kw) |
Line Area(m) - programmable |
Working Speed (M/min.) |
|
|
Circular |
Rectangular/Square |
|||||
|
HG406 |
219-406 |
130mm×130mm–330mm×330mm |
6-16 |
2900KW |
190m*17m |
30 |
