CE Metal Slat Cold Roll Forming Machine 10m / min with Automatic cut
Product of cold roll forming machine
Technical data of cold roll forming machine
|
Suitable Material |
Cold-rolled steel strip and heat-treated galvanized steel strip |
|
Thickness of raw material |
1.0-3.0mm (235-345Mpa) |
|
Size of OMEGA |
50-130mm adjustable (special size available) |
|
Material of roller |
Cr12 mould steel being quenched treatment,HRC58-60 |
|
Material of cutter blade& punching die |
Cr12 mould steel with quenched treatment, HRC58-60 |
|
Material of shaft |
High quality 45# steel with heat treatment. Roller grinder milling. |
|
Forming speed |
about 10-12m/min |
|
Power Requiremen |
Main motor power: 15 Kw(Depend on final design) |
|
Hydraulic station power: 5.5Kw (Depend on final design) |
|
|
Diameter of shaft for rollers |
82mm |
|
Controlling system |
Mitsubishi PLC & converter |
|
Quantity of rollers |
about 22stations for main rollers |
|
Weight of machine |
About 10000KGS |
|
Size of machine installation |
About 23mX2.5mx1.7m |
Our cold roll forming machine’s advantages
1. Anti-rust roller: CNC machine tooled, Plated with 0.05mm hard chrome .
2. Heat treatment: Heat treatment for cutting frame to remove the steel stress, to avoid deformation.
3. Cutter blade: Cr12 mould steel with quenched treatment, long life time.
4. High precision: shafts for rollers are tooled by grinding machine at least twice. Rollers are CNC processed to ensure precision performance.
5. People originate: introduced Mitsubishi PLC with touch screen. Friendly man-machine interaction.
6. Excellent services: Technician can be sent to your factory to install the machine and train your workers. Lifttime services for our machines.
7. All-in-house source: We are \"All-in-house source\" factory to ensure quality and delivery of your machines.
8. Long life: Ensure you our produce machine’s lifetime more than 15 years.
Certificate: ISO 9001, CE,
