Certification:CE, ISO, RoHS
True Sine Wave 3000VA / 2400W Dual Conversion Online Ups Home / Office Ups System Inbuilt SNMP Management Card
Model:High Frequency Online UPS Green Star Series 1K-3Kva (1ph in/1ph out)
Key Features
High frequency and dual conversion on-line technology .
Wide input voltage range .100V-300V
Advanced PFC technology.
True sine wave output with less than 3% THD.
Self-diagnosis at UPS startup .
Advanced battery management(ABM).
Cold start feature(DC power on ).
Automatically charging batteries in UPS off mode.
Lightning and surge protections (surge energy rating 1050 Joules).
Short circuit and overload protections .
Fan speed automatically changes as load varies .
Optional external battery pack .
EMI/RFI noise filter .
RJ11, RS45, RS232(SNMP,USB Optional) .
Shutdown & restart schedule.
ECO Mode for energy saving, and 93% Efficiency under AC Mode at full loads
Technical Specification
| GREEN STAR ONLINE UPS SELECTION GUIDE | ||||
| MODEL | G1K (L) | G2K (L) | G3K (L) | |
| PHASE | Single phase with ground | |||
| CAPACITY | 1000 VA / 800 W | 2000 VA / 1600 W | 3000 VA / 2400 W | |
| INPUT | ||||
| Nominal Voltage | 100/110/115/120/127VAC or 200/208/220/230/240VAC | |||
| Input Voltage Range | 55-145 VAC or 110-300 VAC | |||
| Frequency Range | 40Hz ~ 70 Hz | |||
| Power Factor | ≧ 0.99 @ Nominal Voltage (100% load) | |||
| OUTPUT | ||||
| Output Voltage | 100/110/115/120/127VAC or 200/208/220/230/240VAC | |||
| Voltage Regulation | ± 1% | |||
| Frequency Range (Synchronized Range) | 47~ 53 Hz or 57 ~ 63 Hz | |||
| Frequency Range (Batt. Mode) | 50 Hz or 60Hz ± 0.1 Hz | |||
| Current Crest Ratio | 3:1 | |||
| Harmonic Distortion | ≦ 3 % THD (Linear Load); ≦ 6 % THD (Non-linear Load) | |||
| Transfer Time | AC to DC | Zero | ||
| Inverter to Bypass | 4 ms (Typical) | |||
| Waveform (Batt. Mode) | Pure Sinewave | |||
| EFFICIENCY | ||||
| To AC Mode | 88% | 89% | 90% | |
| To Battery Mode | 83% | 87% | 88% | |
| BATTERY | ||||
| Standard Model | Battery Type | 12 V / 9 AH | 12 V / 7AH | 12 V / 7 AH |
| Numbers | 2 | 6 | 6 | |
| Typical Recharge Time | 4 hours recover to 90% capacity | |||
| Charging Current (max.) | 1.0 A | |||
| Charging Voltage | 27.4VDC ± 1% | 82.1 VDC ±1% | 82.1 VDC ±1% | |
| Long-run Model* | Battery Type | Depending on the capacity of external batteries | ||
| Numbers | 3 | 6 | 8 | |
| Charging Current (max.) | 1.0A/2.0A/4.0A/6.0 A | |||
| Charging Voltage | 41.0VDC ± 1% | 82.1 VDC ±1% | 109.4VDC ±1% | |
| INDICATORS | ||||
| LCD |
Load level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicators |
|||
| ALARM | ||||
| Battery Mode | Sounding every 4 seconds | |||
| Low Battery | Sounding every second | |||
| Overload | Sounding twice every second | |||
| Fault | Continously sounding | |||
| PHYSICAL | ||||
| Standard Model | Dimension, D x W x H (mm) | 397 X 145 X 220 | 419X190X318 | |
| Net Weight (kgs) | 13 | 26 | 28 | |
| Long-run Model* | Dimension, D x W x H (mm) | 282 x |
