JQS-150A Asphalt Mixture Recycling Plant is Designed With Towed Intermittent Forced Mixing Double Drum Asphalt Mixture Recycling Plant

1.PLC control, LCD display, easy operation, stable quality, fault self-diagnosis

    2.Separate measurement and put into the new and old aggregate, double drums rotating, put the new aggregate into inner drum and drying and heating by the burner, put the used aggregate into the outer drum and drying and heating through the waste heat of the inner drum.

    3.Horizontal double drums , Friction wheel driven, drying while drum positive rotate direction, discharging while drum reversion rotate, It is equipped with the imported fuel burner auto-ignition to achieve automatic control and adjustment.

    4.Equipped with twin-shaft mixers, mixing uniformity, high efficiency.

    5.Tornado dust collector device and centrifugal fan, reduce pollution emissions,

    6.Heating the asphalt with the electric tube, simple structure and easy to operate, Asphalt volume measurement, reliable function

    7.Trailer-type chassis, pneumatic device and safety transportation

  Main features：

  The operating principle of recycling plant is first use with the broken used asphalt mixture and the new aggregate, then work by same drum and burner and drying, heating, and then putting into the new asphalt, the work by same drum and burner and drying, heating, and then putting into the new asphalt, then produce the asphalt recycling mixture by forced mixing, The machine fuel is diesel oil and it is equipped with generator sets, then driver the operating device by the motor and heating the asphalt by electric burner and heat transfer oil, it can control the cold aggregate lifting automatically, dry heating and forced mixing, metering and spraying of asphalt, it can be achieved the continuous production with automatic and manual control and failures self-diagnosis function, Widely applicable for highway or city road grade asphalt pavement, it is ideal maintenance equipment.

  Technical parameters：Mechanical

Capacity：

3-4t/h

Generator power：

24kW

The volume of a mixing stirrer：

150kg

Finished material temperature：

120-160℃

The volume of fuel tank：

250/800kg

Operating weight：

6800kg

Overall dimensions (L x W x H)：

6500x2200x3200mm

  Technical parameters：Control

Main power：

380V/50Hz

Sensor analog signal input：

4mA – 20mA

Temperature measuring range：

-200℃-- 500℃

Sensor switch signal voltage：

DC24V

Relays voltage：

DC24V

Contactor voltage：

AC220V

I/O Nos：

DI 14 x DC24v, DO 26x relay, 4-channel analog input

Communication Ports：

RS232

Touch screen(Screen (size & color))：

7” TFT/65536 colors

Communication Ports：

RS232/RS485
