Hydraulic Cutting Wall Panel / Roof Panel Roll Forming Machine For Roof Sheets

Name: Hydraulic Cutting Wall Panel / Roof Panel Roll Forming Machine For Roof Sheets
Brand: RISHBIN
SKU: 149853654
Availability: InStock

Hydraulic Cutting Wall Panel / Roof Panel Roll Forming Machine For Roof Sheets thumbnail-1

Hydraulic Cutting Wall Panel / Roof Panel Roll Forming Machine For Roof Sheets photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

RISHBIN

Place of Origin:

China

Model Number:

RH-WP-10

Contact Supplier Request Quote Chat Now

Rishbin Wuxi Co., Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Product Details
Company Profile
Contact Us

Brand Name RISHBIN

Place of Origin China

Model Number RH-WP-10

Delivery Time:60 working days
Certification:CE

Hydraulic Cutting Wall Panel / Roof Panel Roll Forming Machine For Roof Sheets

Detailed specification of wall panel roll forming machine

Coil Material	Material	PPGI, Color Steel, GI. Aluminium
Coil width	Custom-made
Yield Strength	250Mpa
Thickness	0.3mm-0.8mm
Decoiler	Coil Width	Max. 1250mm
I.D	508-610mm
O.D	Max. 1500mm
Wall Panel Roll Forming Machine	Forming Stations	12-18 Stations ( Depend on Profiles )
Roller material	45# steel, surface coated with 0.05mm hard chrome
Diameter of shaft	76mm
Shaft material	High grade 45# steel
Drive type	Chain transmission
Forming speed	3-15m/min
Main power	5.5KW
Cutting	Cutting type	Hydraulic cutting
Cutting power	4KW
Cutting Tolerance	10m1.5mm
Encoder	OMRON Brand
Electrical control	Operation type	Touch screen & Button
Runout Table	Function	To support the finished panel

Character of main structure

This wall panel structure is simple and the appearance of the machine is beautiful because we adopt the shape-steel structure and process as a whole after welding. It has the ability of strong loading and stable operation when running the machine.
All the components of machine are from brand-famous enterprise so that they ensure the machine normal function very effectively.
We adopt the automatic length-fixed forming and cutting to guarantee the length to be precise and the finished product clear without deforming .
It is very easy to install the equipment and suitable for producing in the factory.
The machine has features of low noise and high efficiency
