Help CenterHigh-efficiency Complex Crusher GXF
Related Products
Advantages and characteristics
1. Combined coarse-crushing and free-crushing, make crush process simplify
2. Reduce the power consume
3. Low cost of machine
4. Low cost of maintenance
Brief introduction
This type of crusher is used in areas of cement, construction material and mining industries for the materials with breaking strength no stronger the 200Mpa. The size of feeding materials is up to 450-1000mm and the average discharge size is <=5-8mm, which is controlled effectively by multi-mode elastic adjusting mechanism. Unique design: Back cover of upper case can be opened with hydraulic pressure (or hand operated) and replace a component which is for easy maintenance. This feature has created the history of production of cement raw material in China by reducing 1/3 investment on the equipment and saving half of the power consumption as well as less maintenance cost. (Output from 40t/h to 500t/h).
|
Model |
Max.feed size (mm) |
Average discharge size(mm) |
Capacity(t/h) |
Electric motor power(kw) |
Weight(t) |
Overall dimension(mm) |
|
GXF-40 |
450 |
3-5 |
35-45 |
75 |
12 |
2231*1940*2168 |
|
GXF-60 |
500 |
5-8 |
55-65 |
110 |
18 |
2550*2850*2670 |
|
GXF-80 |
500 |
5-8 |
75-85 |
132 |
21 |
2550*2630*2670 |
|
GXF-100 |
600 |
5-8 |
90-110 |
185 |
25 |
2550*3120*2670 |
|
GXF-120 |
600 |
5-8 |
110-130 |
200 |
28 |
2550*3390*2670 |
|
GXF-160 |
700 |
5-8 |
140-180 |
250 |
32.5 |
2793*3140*3014 |
|
GXF-200 |
700 |
5-8 |
190-220 |
280 |
38.5 |
2793*3410*3014 |
|
GXF-300 |
1000 |
8-12 |
280-340 |
450 |
55 |
3670*3850*4135 |
|
GXF-400 |
1000 |
8-12 |
3890-420 |
560 |
65 |
3670*4180*4135 |
|
GXF-500 |
1000 |
8-12 |
460-520 |
710 |
75 |
3670*4500*4135 |
