2 Post Car Lift_auto Lift Exporter_hydraulic Lift Supplier

1.Single point safety release

2.Lift mechanisms through a hydraulic group ,which operates over hydraulic cylinders of simple effect

3.very stable and equilibrated of easy  use ,thinking in the mechanic needs.

4.slient and with a highest space optimization of the work area

5.suitable for any type  of cars and repairs

6.semi-base low profile:34mm height

with worker safety device:thought 14 wedges ,the weight is supported by it leaving the chains in repose

8.Design with carriage synchronization and safety against obstacles by wire

9.two cylinders ensure the maximum stability

10.quality engineering to ensure the highest working safety ,longer life time and to reduce maintenance  interventions to the minimum

Specifications: (As per one set)

Lifting capacity

7000LB/3.2T

Overall height

2942mm

Overall width

3221mm

Maximum lifting height

1927mm

Motor capacity

2.2kw/3HP

Drive through

2370mm

Lifting time

60s

Width between post

2651mm”

Min. pad height

127.5mm

N.W.(Kg)

460

G.W.(Kg)

480

L×W×H(mm)

2750*740*520
