Oil Wells Filtering Fine Particle Monel / Hastelloy / Inconel Perforated Round Tube

Delivery Time:25-35 days
Certification:ISO

Straight Weld Round 1/4’’-12’’  strong anti-pressure ability Longitudinal Welded Perforated Tube used as filter frame

Forward Filter & Fitting Co. has rich experience in perforated tubes manufacture and we

 know perforated tubes from materials, processing, welding, special treatment to its

applications.

Description:

Aka: Perforated Tube, Perforated Pipe, Center Tube of Filter Element

Material: Ss304/304L/316/316L stainless steel, Mild steel, Aluminum, Copper, Monel, Hastelloy, Inconel, Titanium, etc.

Perforated Tubing Capabilities: High Speed Hole Punching, Cut-To-Length Perforated Tubing

Perforation Patterns: Straight, Centers, Staggered

Seam Styles: Straight Weld, Spiral Weld, Spiral Welded Louvered

Shape of Hole: Round, Square, Rectangle, Oval, Special Shape

Hole Diameter: Various to meet different requirements for tubing strength and filtration

Tube Diameter(Round): 1/4’’-12’’ (6.35 ～ 304.8mm)

Wall Thickness: 0.5～2.5mm (various types can be customized )

Length: Customized

Features: uniform punching hole, strong anti-pressure ability, can be used as filter frame, big bearing, high

roundness, precise filtering capacity.

Uses:

(1) Protective sleeve for sand control screens

(2) Support core for strainers

(3) Purolator suction strainers

(4) Acoustical dampening

(5) Perforated tubes for oil well

(6) Exhaust tubes, Muffler tube

(7) Filtration / Separation Tubes (e.g center tube for air, oil, fuel, gas filters)

(8) Decorative items

(9) Gas / Liquid / Vapor/ Light Diffusion

(10)Structural Members

Basic Specification:

Perforation Patterns	Straight, Centers, Staggered
Seam Styles	Straight Weld
Tube Shapes	Round, Rectangle, Square, Oval, Special Shape
Hole Diameter	Various to meet different requirements for tubing strength and filtration
Tube Diameter (Round)	1/4’’ ～ 12’’
Wall Thickness	0.2～2.5mm (special types can be customized )
Length	Customized
Application	Exhaust Tubes, silencer tube, safety guards,  Filtration / Separation Tubes for water treatment, Decorative Items, Gas / Liquid Diffusion Tubes, Structural Members, Food Processing

Note: Special specifications can be customized!
